Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Deore, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Metrix Rigid Alloy 6061 / Metrix Men geometry Internal cable routing
Suspension Fork
Alloy Rigid fork 11/8"
Drivetrain
Rear Derailleur
Shimano Deore RD-M592 27 Speed
Front Derailleur
Shimano FD-M370 / 31.8mm
Shift Levers
Shimano SL-M370 R-fire plus
Cassette
Shimano CS-HG200-9 11-32 T
Crank
Shimano FC-T4010-L 48x38x28 w/CG
Bottom Bracket
Shimano BB-ES300
Chain
KMC X9
Wheels
Front Hub
Formula CL 51
Rear Hub
Shimano FH-RM33 CL
Rims
Syncros X-39 700C, 32H, black
Spokes
Stainless black, 14G / 2mm
Tires
Kenda K180 700x38C / 30 TPI
Brakes
Brakes
Shimano BR-M355 Hydr. Disc 160F/160R mm RT20 Rotor
Cockpit
Stem
Syncros UC3.0 31.8mm
Handlebar
Syncros UC3.0 Tbar 620mm, 9° bend
Headset
Ritchey OE Logic Zero, semi integrated
Seat
Saddle
Metrix Men EVO
Seatpost
Syncros UC3.0 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.53 mm | 1.56 mm | 1.57 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 635 mm | 651 mm | 667 mm | 688 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 78 mm | 78 mm | 78 mm | 78 mm |
| Stack | 604.7 mm | 618.8 mm | 642.3 mm | 665.8 mm |
| Reach | 393 mm | 403.7 mm | 411.5 mm | 424.3 mm |
| Top Tube Length | 576 mm | 591 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 570 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 160 mm | 185 mm | 210 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1089 mm | 1104 mm | 1121 mm | 1142 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 772 mm | 801 mm | 832 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Metrix 10 completes the Scott Metrix model. 16 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Metrix 10 components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When leaving the production line, the Metrix 10 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Scott Metrix 10 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
