Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Metrix Disc / 6061 D.Butted Alloy Endurance geometry / Integrated Headtube
Suspension Fork
Metrix Disc Alloy 1 1/8" Alloy steerer
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-GS 16Speed
Front Derailleur
Shimano Claris FD-R2000
Shift Levers
Shimano SL-R2000
Cassette
Shimano CS-HG50 8 Speed 11-32 T
Crank
Shimano FC-RS200 50x34 T
Bottom Bracket
Shimano BB-RS500
Chain
KMC X8
Wheels
Front Hub
Formula Team CL Disc 28 H
Rear Hub
Formula Team CL Disc 28 H
Rims
Syncros Race 22 Disc 28 Front / 28 Rear
Spokes
SHA-DAR Black 2mm
Tires
Schwalbe Spicer 700x35C
Brakes
Brakes
Shimano BR-RS405 Hyd Disc160/F and 160/R mm SM-RT70 CL Rotor
Brake Levers
Shimano BL-RS600
Cockpit
Stem
JD ST123A Alloy 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros Flat-Bar FL2.0 580mm
Headset
Integrated Steel Cup
Seat
Saddle
Syncros FL2.5
Seatpost
Syncros RR2.5 27.2/300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.46 mm | 1.5 mm | 1.54 mm | 1.57 mm | 1.54 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 568 mm | 574 mm | 576 mm | 581 mm | 586 mm | 593 mm | 607 mm |
| Rake | 36 mm | 36 mm | 35 mm | 35 mm | 35 mm | 35 mm | 40 mm |
| Trail | 85 mm | 82 mm | 77 mm | 73 mm | 70 mm | 68 mm | 63 mm |
| Stack | 518.7 mm | 529.9 mm | 552.5 mm | 573.3 mm | 594.3 mm | 614.5 mm | 615.6 mm |
| Reach | 368.6 mm | 375.5 mm | 379.3 mm | 383.2 mm | 386.6 mm | 391 mm | 399 mm |
| Top Tube Length | 507 mm | 517 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.1 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.3 ° | 73.3 ° |
| Head Tube Length | 111 mm | 121 mm | 141 mm | 161 mm | 181 mm | 201 mm | 221 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 975 mm | 981 mm | 983 mm | 988 mm | 993 mm | 1001 mm | 1014 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 727 mm | 743 mm | 769 mm | 789 mm | 809 mm | 829 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
Metrix 30 disc completes the Scott Metrix model. There are 16 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Fitness bikes
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Scott Metrix 30 disc it’s weighing 10.9 kg (24.03 lbs). At this weight, is slightly lighter than average. To sum up, it’s 3.12% lighter than the average weight of Fitness bikes.
Metrix 30 disc components
Fork material
Metrix 30 disc has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Metrix 30 disc model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Scott Metrix 30 disc has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, you can easily find one that suits you.
