Scott Patron eRIDE 930 2023
2023 E-bike
Estimate price |
7,225$
Weight | 26.1 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Domain
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery PowerTube 625Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy Frame & Link Virtual 4 link kinematic VLK 29x2.6 / Boost 148x12mm UDH 160mm travel / Bosch Gen4 / Integr. removable Battery 1.8" Headtube, Central Kickstand Mount Integr. Cable
Suspension Fork
RockShox Domain Air 15x110mm QR axle / 1.8" Tapered Steerer Reb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
Rear Shock
X-Fusion NUDE eRIDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 160-115-Lockout / 205x60mm
Drivetrain
Rear Derailleur
SRAM NX Eagle / 12 Speed
Shift Levers
SRAM SX Eagle Single Click
Cassette
SRAM PG1210 / 11-50 T
Crank
FSA CK-745 165mm / 34T
Bottom Bracket
Bosch, press-fit
Chain
SRAM SX Eagle
Wheels
Front Hub
Formula CL-811 / 15x110mm
Rear Hub
Formula ECT-1481 / Boost 148x12mm
Rims
Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
Spokes
Stainless Black
Tires
Front: Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra, Rear: Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra
Brakes
Brakes
SRAM DB8 4 Piston Disc
Cockpit
Stem
Syncros AM2.0 / 6061 Alloy 31.8mm / 4° / 1 1/8"
Handlebar
Syncros Hixon 2.0 / Alloy 6061D.B. 12mm rise / 9° / 780mm Syncros Endurance lock-on grips
Headset
Acros / 1.8" ZS66 OD74 / integr. Cable
Seat
Saddle
Syncros Tofino 2.5 Regular
Seatpost
Syncros Duncan Dropper Post 2.5 31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm
Motor & Battery
Motor
Bosch Performance CX EU: 25kmh / INT: 20mph
Battery
PowerTube 625Wh
Charger
4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.45 mm | 1.38 mm | 1.32 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 769 mm | 779 mm | 811 mm | 843 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 133.3 mm | 129.5 mm | 129.5 mm | 129.5 mm |
| Stack | 628.3 mm | 635.7 mm | 644.8 mm | 653.9 mm |
| Reach | 426.2 mm | 439.3 mm | 467.1 mm | 494.7 mm |
| Top Tube Length | 572.9 mm | 588.5 mm | 619.1 mm | 649.9 mm |
| Seat Tube Angle | 77 ° | 76.9 ° | 76.9 ° | 76.8 ° |
| Seat Tube Length | 410.5 mm | 440.5 mm | 470.4 mm | 500.4 mm |
| Head Tube Angle | 64.5 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1215 mm | 1225 mm | 1257 mm | 1288 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 759 mm | 759 mm | 759 mm | 759 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Patron eRIDE 930 is part of the Scott E Patron model. There are 20 e-bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Scott Patron eRIDE 920 2023 is the cheapest e-bike model and costs 6299$. Scott Patron eRIDE 900 Ultimate 2023 is the most expensive one and costs 14596$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
When Scott released this model in 2023, its price was 6567$. Comparing this to the average Enduro e-bike price, we see that the price is 37.24% more expensive.
Enduro e-bikes average weight
If we make a quick analysis of the average weight of an Enduro e-bike, we get 23.42 kg (51.63 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 26.1 kg (57.54 lbs), Scott e-bike is considerably heavier than average. To sum up, it’s 11.44% heavier than the average weight of Enduro e-bikes.
Overview of components
Fork
Scott Patron eRIDE 930 2023 e-bike is equipped with the RockShox Domain fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Patron eRIDE 930 has a rear shock with a travel of 160mm. The model X-Fusion NUDE eRIDE Trunnion SCOTT custom is the one installed in this e-bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Patron eRIDE 930 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Patron eRIDE 930 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
