Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Plasma 4 / IMP technology / HMF TT / TRI Geometry / Plasma HMX seatpost / Replaceable hanger / UCI approved
Suspension Fork
Plasma 4 1 1/8" Carbon / integrated
Drivetrain
Rear Derailleur
Shimano Ultegra RD-R8000 22 Speed
Front Derailleur
Shimano Ultegra FD-R8000
Shift Levers
Shimano Dura Ace SL-BSR1 bar end
Cassette
Shimano Ultegra CS-R8000 11-28
Crank
Shimano Ultegra FC-R8000 39/53 T
Bottom Bracket
Shimano SM-BB72-41B
Chain
Shimano CN-HG701-11
Wheels
Front Hub
Formula RB 25
Rear Hub
Formula RB 2611
Rims
Syncros Race 22 Aero Profile 24 Front / 28 Rear
Spokes
CN - Standard Black 2mm
Tires
Continental Grand Sport Race 700x25C Fold
Brakes
Brakes
Front: Shimano Ultegra BR-R8010F Rear: Shimano Ultegra BR-R8010R, direct mount
Brake Levers
Profile Design 3 / one A
Cockpit
Stem
Profile 1/ZeroSeven 1 1/8"-31.8mm-7°
Handlebar
Profile OZERO TT Profile T2+ Carbon J5
Headset
Syncros Integrated 45mm drop-in headset
Seat
Saddle
Syncros RR2.0 TRI
Seatpost
Plasma HMX with Ritchey WCS clamp adjustable head
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.37 mm | 1.38 mm | 1.4 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 571 mm | 589 mm | 615 mm | 635 mm |
| Rake | 41 mm | 41 mm | 41 mm | 41 mm |
| Trail | 66 mm | 60 mm | 60 mm | 57 mm |
| Stack | 503.8 mm | 533.8 mm | 563.8 mm | 593.8 mm |
| Reach | 373.8 mm | 390.8 mm | 407.8 mm | 423.8 mm |
| Top Tube Length | 517.8 mm | 537.8 mm | 557.8 mm | 576.8 mm |
| Seat Tube Angle | 74 ° | 75 ° | 75 ° | 76 ° |
| Seat Tube Length | 529.8 mm | 559.6 mm | 589.4 mm | 619.2 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 110 mm | 138 mm | 170 mm | 199 mm |
| Chainstay Length | 396 mm | 396 mm | 396 mm | 396 mm |
| Wheelbase | 958 mm | 976 mm | 1002 mm | 1022 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 772 mm | 802 mm | 832 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Plasma 10 is part of the Scott Plasma model. Scott released 18 bikes variations of this model so far. You can easily view all of the Scott Plasma bikes models from 2018, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Triathlon bikes average price
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Triathlon bikes average weight
The average weight for Triathlon bikes is 8.9 kg (19.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Scott Plasma 10 it’s weighing 8.7 kg (19.18 lbs). At this weight, is slightly lighter than average. In short, the average Triathlon bike weight is 2.3% higher than this one.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Plasma 10 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
