Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCR
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Scale 700 Alloy Custom Butted Superlight Tubing / Tapered HT BB92 / 3.0" Tire clearance / Full Internal Cable Routing IDS SL DM dropouts for 12x148mm Boost
Suspension Fork
Suntour XCR RL-R / Coil Spring 15 x110mm QR axle / Tapered Steerer / Reb. Adj Remote Lockout / 120mm travel
Drivetrain
Rear Derailleur
SRAM NX1 / 11 Speed
Shift Levers
SRAM NX1 Trigger
Cassette
SRAM PG1130 / 11-42 T
Crank
SRAM NX1 GXP Boost PF 30T
Bottom Bracket
SRAM GXP PF integrated / shell 41x89.5mm
Chain
SRAM PC1110
Wheels
Front Hub
Formula CL811 / 15x110mm
Rear Hub
Formula CT1702 / 5x141mm
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint Tubeless ready
Spokes
Stainless Black 15G / 1.8mm
Tires
Maxxis Rekon / 2.80x27.5 / 60TPI Kevlar Bead TR Tubeless ready
Brakes
Brakes
Shimano M365 Disc 180/F and 160/Rmm SM-RT30 CL Rotor
Cockpit
Stem
Syncros 6061 Alloy oversize 31.8mm / 1 1/8" / 6° angle
Handlebar
Syncros FL2.0 mini Riser / Alloy 6061D.B. 12mm rise / 9° / 740mm
Headset
Syncros OE Press Fit / Tapered 1.5" - 1 1/8" OD 50/61mm / ID 44/55mm
Seat
Saddle
Syncros XM2.5
Seatpost
Syncros / 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.48 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 675 mm | 700 | 726 mm | 752 mm |
| Rake | 40 mm | 40 mm | 39 mm | 39 mm |
| Trail | 111 mm | 111 mm | 112 mm | 112 mm |
| Stack | 614 mm | 619 mm | 628 mm | 638 mm |
| Reach | 396 mm | 419 mm | 442 mm | 464 mm |
| Top Tube Length | 584 mm | 609 mm | 634 mm | 659 mm |
| Seat Tube Angle | 72.8 ° | 72.8 ° | 72.8 ° | 72.8 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1115 mm | 1140 mm | 1166 mm | 1192 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 787 mm | 813 mm | 836 mm | 864 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Scale 730 completes the Scott Scale model. Scott launched 183 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Scale 730 weighs 13.1 kg (28.88 lbs) and is slightly heavier than the average. To sum up, it’s 0.92% heavier than the average weight of Trail bikes.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This bike has the SunTour XCR fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Scale 730 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Scale 730 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
