Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Rhythm Float 32
-
Groupset NX, NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Scale 3 Carbon / IMP technology / HMF BB92 / SW DM dropouts for Boost 12x148mm SDS2 advanced Shock & Standing Damping System ICCR Cable routing
Suspension Fork
FOX 32 Float Rhythm Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer Reb. Adj. / Lockout / 100mm travel
Drivetrain
Rear Derailleur
SRAM NX / Eagle 12 Speed
Shift Levers
SRAM NX Eagle Trigger
Cassette
SRAM NX / XG1230 / 11-50 T
Crank
SRAM NX Eagle DUB Boost 32T
Bottom Bracket
SRAM DUB PF integrated / shell 41x92mm
Chain
SRAM CN NX Eagle
Wheels
Front Hub
Shimano HB-MT400-B CL / 15x110mm
Rear Hub
Shimano FH-MT400-B CL / Boost 12x148mm
Rims
Syncros X-25 / 32H / 25mm Tubeless ready
Spokes
Stainless Black 15G / 1.8mm
Tires
Maxxis Rekon Race / 2.25" / 60TPI Kevlar Bead TR Tubeless Ready / EXO
Brakes
Brakes
Shimano MT400 Disc 180/F and 160/R mm SM-RT54 CL Rotor
Cockpit
Stem
Syncros FL2.0 6° / integrated Spacer & Top Cup 6061 Alloy / 31.8mm / 1 1/8"
Handlebar
Syncros FL2.0 T-Bar / Alloy 6061 T shape Flat / 9° / 720mm Syncros Pro lock-on grips
Headset
Syncros Pro Drop in / Tapered 1.5"-1 1/8" bearing diameter size 42mm and 52mm
Seat
Saddle
Syncros XR2.0 / CROM rails
Seatpost
Syncros FL2.5 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.42 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 658 mm | 683 mm | 709 mm | 735 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 83.9 mm | 83.9 mm | 83.9 mm | 83.9 mm |
| Stack | 606 mm | 610.6 mm | 624.7 mm | 634.1 mm |
| Reach | 405.7 mm | 429.3 mm | 450.2 mm | 472.5 mm |
| Top Tube Length | 582 mm | 607 mm | 632 mm | 657 mm |
| Seat Tube Angle | 73.6 ° | 73.6 ° | 73.6 ° | 73.6 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 125 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1083 mm | 1108 mm | 1134 mm | 1160 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 750 mm | 781 mm | 807 mm | 842 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Scale 930 is a Scott Scale model. 183 bikes variations carry this model name so far. You can easily view all of the Scott Scale bikes models from 2019, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
a bit lighter than average, Scale 930 has a weight of 11.3 kg (24.91 lbs). In other words, this model is 9.73% lighter than the average Crosscountry bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This bike has the Fox Rhythm Float 32 fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Scott Scale 930 2019, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Scale 930 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Scott Scale 930 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
