Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Elite Float 34
-
Groupset X01, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Carbon / IMP technology / HMF Mainframe BB92 / Alloy SL 6011 swingarm SW dropouts for Boost 148x12mm TBC Trunnion box construction
Suspension Fork
FOX 34 Float Performance Elite Air FIT4 3-Modes with low speed adj. / 15x110mm QR axle tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend DPS / EVOL / Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Drivetrain
Rear Derailleur
SRAM X01 / Eagle 12 Speed
Front Derailleur
SCOTT Chainguide
Shift Levers
SRAM X01 Trigger
Cassette
SRAM X01 / XG1295 / 10-50 T
Crank
SRAM X1 1400 Eagle GXP Boost PF 700 Series: 34T / 900 Series: 32T
Bottom Bracket
SRAM GXP PF integrated / shell 41x92mm
Chain
SRAM PCX01 Eagle
Wheels
Front Hub
Syncros XR2.0 CL / 15x110mm made by DT Swiss
Rear Hub
Syncros XR2.0 CL / Boost 148x12mm RWS axle / made by DT Swiss
Rims
Syncros XR2.0 / 28H / Tubeless ready
Spokes
DT Swiss Competition 2.0-1.8-2.0 Black
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead TR Tubeless Ready / EXO / 3C maxx speed
Brakes
Brakes
Shimano XT M8000 Disc 180mm F & R / SM-RT64 CL Rotor
Cockpit
Stem
Syncros FL1.5 / Alloy 2014 integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Handlebar
Syncros FL1.5 T-Bar / Alloy 7050 D.B. T shape Flat / 9° / 740mm Syncros Pro lock-on grips
Headset
Syncros FL2.0 Drop in / Tapered 1.5" - 1 1/8" bearing diameter size 42mm and 52mm
Seat
Saddle
Syncros XR1.5 / Titanium rails
Seatpost
FOX Transfer Dropper Remote 31.6mm / S size 100mm / M, L & XL 125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.31 mm | 1.26 mm |
| Bottom Bracket Height | 325.5 mm | 325.5 mm | 325.5 mm |
| Front Center | 688 mm | 719 mm | 750 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 101.4 mm | 101.4 mm | 101.4 mm |
| Stack | 561.9 mm | 566.5 mm | 575.7 mm |
| Reach | 402.7 mm | 431.4 mm | 458.7 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1108 mm | 1138 mm | 1170 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm |
| Standover Height | 718 mm | 726 mm | 741 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Spark 700 completes the Scott Spark model. Scott released 189 bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Scott Spark 700 it’s weighing 11.9 kg (26.23 lbs). At this weight, is a bit lighter than average. To sum up, it’s 9.08% lighter than the average weight of Trail bikes.
Spark 700 components
Fork
The Fox Performance Elite Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the FOX NUDE Trunnion SCOTT custom w. model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Scott Spark 700 2017, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Spark 700 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
