Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Carbon / IMP technology / HMF Mainframe BB92 / Alloy SL 6011 swingarm SW dropouts for Boost 148x12mm TBC Trunnion box construction custom Chainguide
Suspension Fork
FOX 34 Float Performance Air Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend DPS / EVOL / Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Drivetrain
Rear Derailleur
SRAM GX1 / 11 Speed
Shift Levers
SRAM GX1 Trigger
Cassette
SRAM XG1150 / 10-42 T
Crank
SRAM Custom GX1 GXP Boost PF 700 Series: 32T / 900 Series: 30T
Bottom Bracket
SRAM GXP PF integrated / shell 41x92mm
Chain
SRAM CN-PC1110
Wheels
Front Hub
Syncros 3.0 / TC-711 / 15x110mm made by Formula
Rear Hub
Syncros 3.0 / TC-14811 / Boost 148x12mm RWS axle / XD / made by Formula
Rims
Syncros 3.0 / 28H / Tubeless ready
Spokes
Xero Forza / 2.0 Black / Nyloc
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead TR Tubeless Ready / EXO / 3C maxx speed
Brakes
Brakes
Shimano M506 Disc 180mm F & R / SM-RT54 CL Rotor
Cockpit
Stem
Syncros FL2.0 / 6061 Alloy 6° / integrated Top Cup / 31.8mm / 1 1/8"
Handlebar
Syncros FL1.5 T-Bar / Alloy 7050 D.B. T shape Flat / 9° / 740mm Syncros Pro lock-on grips
Headset
Syncros Pro Drop in / Tapered 1.5" - 1 1/8" bearing diameter size 42mm and 52mm
Seat
Saddle
Syncros XR2.0 / CROM rails
Seatpost
Syncros Dropper 2.0 / YSP12 ICR / Remote 31.6mm / S size 100mm / M, L & XL 120mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.31 mm | 1.26 mm |
| Bottom Bracket Height | 325.5 mm | 325.5 mm | 325.5 mm |
| Front Center | 688 mm | 719 mm | 750 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 101.4 mm | 101.4 mm | 101.4 mm |
| Stack | 561.9 mm | 566.5 mm | 575.7 mm |
| Reach | 402.7 mm | 431.4 mm | 458.7 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1108 mm | 1138 mm | 1170 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm |
| Standover Height | 718 mm | 726 mm | 741 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Spark 730 completes the Scott Spark model. There are 189 bikes that carry this model name. Take a sneak peek at all Scott Spark bikes models from 2017, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 12.2 kg (26.9 lbs), the Spark 730 model is a bit lighter than average. In conclusion, the average Trail bike weighs 6.39% more than Spark 730.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is FOX NUDE Trunnion SCOTT custom w., with a travel distance of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Scott Spark 730 2017, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Spark 730 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Spark 730 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
