Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Alloy SL 6011 custom butted Hydroformed tubes tapered Headtube / BB92 dropouts for 141x5mm
Suspension Fork
Rock Shox Recon Silver RL Solo Air 15x100mm QR axle / Tapered Steerer Reb. Adj. / Lockout / 120mm travel
Rear Shock
X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Drivetrain
Rear Derailleur
Shimano SLX RD-M7000-10 SGS Shadow Type / 20 Speed
Front Derailleur
Shimano Deore FD-M617-D / / side swing
Shift Levers
Shimano Deore SL-M610 / Rapidfire Plus 2 way releasew/gear indicator
Cassette
Shimano CS-HG50-10 / 11-36 T
Crank
Shimano FC-M627-B2 / 2-piece Design 36x22 T
Bottom Bracket
Shimano BB-MT500-PA / shell 41x89.5mm
Chain
KMC X10
Pedals
Wellgo M-21
Wheels
Front Hub
Formula CL71 / 15x100mm
Rear Hub
Formula CT1702 / 141x5mm
Rims
Syncros X-23 / 32H / Tubeless ready
Spokes
Stainless Black 15G / 1.8mm
Tires
Maxxis Forekaster / 2.35 / 60TPI
Brakes
Brakes
Shimano M365 Disc 180mm F & R / SM-RT30 CL Rotor
Cockpit
Stem
Syncros 6061 Alloy oversize 31.8mm / 1 1/8" / 6° angle
Handlebar
Syncros T-Bar / Alloy 6061 T shape Flat / 9° / 740mm
Headset
Syncros OE Press Fit / Tapered 1.5" - 1 1/8" OD 50/61mm / ID 44/55mm
Seat
Saddle
Syncros XR2.5
Seatpost
Syncros / 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.31 mm | 1.26 mm |
| Bottom Bracket Height | 325.5 mm | 325.5 mm | 325.5 mm |
| Front Center | 688 mm | 719 mm | 750 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 101.4 mm | 101.4 mm | 101.4 mm |
| Stack | 561.9 mm | 566.5 mm | 575.7 mm |
| Reach | 402.7 mm | 431.4 mm | 458.7 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1108 mm | 1138 mm | 1170 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm |
| Standover Height | 718 mm | 726 mm | 741 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Spark 760 is part of the Scott Spark model. 189 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 13.6 kg (29.98 lbs), the Spark 760 model is slightly heavier than average. In conclusion, the average Trail bike weighs 4.78% less than Spark 760.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the X-Fusion NUDE Trunnion SCOTT custom w. rear shock model, which has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, Scott Spark 760 2017, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Spark 760 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Scott Spark 760 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
