Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XX1, XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Carbon / IMP technology / HMX BB92 / Carbon swingarm SW dropouts for Boost 12x148mm TBC Trunnion box construction
Suspension Fork
FOX 34 Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / 15x110mm QR axle tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend DPS / Kashima / Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Drivetrain
Rear Derailleur
SRAM XX1 / Eagle 12 Speed
Front Derailleur
SCOTT Chainguide
Shift Levers
SRAM XX1 Trigger
Cassette
SRAM XX1 / XG1299 / Gold / 10-50 T
Crank
SRAM XX1 Eagle GXP Boost PF Carbon crankarm QF 168 / 32T
Bottom Bracket
SRAM GXP PF integrated / shell 41x92mm
Chain
SRAM PCXX1 Gold Eagle
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: DT Swiss XRC 1200, Boost 15mm x 110mm, Rear: DT Swiss XRC 1200, Boost 12mm x 148mm
Rear Hub
Front: DT Swiss XRC 1200, Boost 15mm x 110mm, Rear: DT Swiss XRC 1200, Boost 12mm x 148mm
Rims
DT Swiss XRC 1200 Carbon Spline CL F: 15x110mm, R: 12 x 148mm Boost 25mm Tubless ready rim / 28H / XD DT RWS w/Removable Lever with Tool
Spokes
DT Swiss
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead TR Tubeless Ready / EXO / 3C maxx Speed Syncros Eco Sealant
Brakes
Brakes
SRAM Level Ultimate Disc / tool free reach adj 180/F and 160/Rmm Centerline CLX Rotor
Brake Levers
SRAM Level Ultimate
Cockpit
Stem
Syncros FL1.5 / Alloy 2014 integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8" Garmin mount
Handlebar
Syncros FL1.0 Carbon T-Bar T shape flat / 9° / 740mm Syncros Pro lock-on grips
Grips
Syncros Pro Lock-on
Headset
Syncros FL1.5 Drop in / Tapered 1.5" - 1 1/8" Ti bearing diameter size 42mm and 52mm
Seat
Saddle
Syncros XR1.0 / Carbon rails
Seatpost
FOX Transfer Dropper Remote Kashima / 31.6mm / S size 100mm / M, L & XL 125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.38 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm | 327 mm |
| Front Center | 687 mm | 717 mm | 748 mm | 769 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 100.2 mm | 100.2 mm | 100.2 mm | 100.2 mm |
| Stack | 586.1 mm | 586.1 mm | 595.4 mm | 604.6 mm |
| Reach | 395.7 mm | 425.7 mm | 453 mm | 470.3 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1114 mm | 1144 mm | 1175 mm | 1196 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 731 mm | 739 mm | 753 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Spark 900 Ultimate belongs to the Scott Spark model. There are 189 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 10.9 kg (24.03 lbs), the Spark 900 Ultimate model is much lighter than average. In conclusion, the average Trail bike weighs 19.08% more than Spark 900 Ultimate.
Spark 900 Ultimate components
Fork
Scott Spark 900 Ultimate 2018 bike is equipped with the Fox Factory Float 34 fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the FOX NUDE EVOL Trunnion SCOTT custom rear shock model, which has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Scott Spark 900 Ultimate 2018, has a 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Spark 900 Ultimate has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Spark 900 Ultimate comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The Scott model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
