Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 34
-
Groupset NX, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Carbon / IMP technology / HMF Mainframe BB92 / Alloy SL 6011 swingarm SW dropouts for Boost 12x148mm 2.6 tire compatible / TBC Trunnion box construction
Suspension Fork
FOX 34 Float Rhythm Air Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control -Descend DPS / Reb. Adj. / Travel 120-85-Lockout / 165X45mm
Drivetrain
Rear Derailleur
SRAM NX / Eagle 12 Speed
Shift Levers
SRAM NX Eagle Trigger
Cassette
SRAM NX / XG1230 / 11-50 T
Crank
SRAM NX Eagle DUB Boost 32T
Bottom Bracket
SRAM DUB PF integrated / shell 41x92mm
Chain
SRAM CN NX Eagle
Chain Guide
SCOTT custom
Wheels
Rims
Syncros Silverton 2.5 6 Bolt F: 15x110mm, R: 12x148mm Boost 25mm Tubeless ready rim / 28H / DT RWS
Tires
Maxxis Rekon / 2.4" / 120TPI Kevlar Bead TR Tubeless Ready / EXO 3C maxx Terra
Brakes
Brakes
Shimano SLX M7000 Disc 180mm F&R SM-RT66 Rotor
Cockpit
Stem
Syncros FL2.0 / 6061 Alloy 6° / integrated Top Cup / 31.8mm / 1 1/8"
Handlebar
Syncros FL2.0 T-Bar / Alloy 6061 T shape Flat / 9° / 740mm Syncros Pro lock-on grips
Headset
Syncros Pro Drop in / Tapered 1.5"-1 1/8" bearing diameter size 42mm and 52mm
Seat
Saddle
Syncros XR2.0 / CROM rails
Seatpost
Syncros Dropper 2.0 Remote 31.6mm / S size 100mm / M, L & XL 120mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.38 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm | 327 mm |
| Front Center | 687 mm | 717 mm | 748 mm | 769 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 100.2 mm | 100.2 mm | 100.2 mm | 100.2 mm |
| Stack | 586.1 mm | 586.1 mm | 595.4 mm | 604.6 mm |
| Reach | 395.7 mm | 425.7 mm | 453 mm | 470.3 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1114 mm | 1144 mm | 1175 mm | 1196 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 731 mm | 739 mm | 753 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Spark 930 belongs to the Scott Spark model. Scott launched 189 bikes of this model so far. Take a sneak peek at all Scott Spark bikes models from 2019, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Spark 930 weighs 13.1 kg (28.88 lbs) and is slightly heavier than the average. In conclusion, the average Trail bike weighs 0.92% less than Spark 930.
Spark 930 components
Fork
This bike has the Fox Rhythm Float 34 fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the FOX NUDE EVOL Trunnion SCOTT custom rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Spark 930 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Spark 930 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Scott Spark 930 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
