Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spark 3 Alloy SL 6011 custom butted Hydroformed tubes tapered Headtube / BB92 dropouts for 141x5mm
Suspension Fork
Rock Shox Recon Silver RL Solo Air 15x100mm QR axle / Tapered Steerer Reb. Adj. / Lockout / 120mm travel
Rear Shock
X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Drivetrain
Rear Derailleur
Shimano SLX RD-M7000-10 SGS Shadow Type / 20 Speed
Front Derailleur
Shimano Deore FD-M617-D / / side swing
Shift Levers
Shimano Deore SL-M610 / Rapidfire Plus 2 way releasew/gear indicator
Cassette
Shimano CS-HG50-10 / 11-36 T
Crank
Shimano FC-M627-B2 / 2-piece Design 36x22 T
Bottom Bracket
Shimano BB-MT500-PA / shell 41x89.5mm
Chain
KMC X10
Pedals
Wellgo M-21
Wheels
Front Hub
Formula CL71 / 15x100mm
Rear Hub
Formula CT1702 / 141x5mm
Rims
Syncros X-23 / 32H / Tubeless ready
Spokes
Stainless Black 15G / 1.8mm
Tires
Maxxis Forekaster / 2.35 / 60TPI
Brakes
Brakes
Shimano M365 Disc 180mm F & R / SM-RT30 CL Rotor
Cockpit
Stem
Syncros 6061 Alloy oversize 31.8mm / 1 1/8" / 6° angle
Handlebar
Syncros T-Bar / Alloy 6061 T shape Flat / 9° / 740mm
Headset
Syncros OE Press Fit / Tapered 1.5" - 1 1/8" OD 50/61mm / ID 44/55mm
Seat
Saddle
Syncros XR2.5
Seatpost
Syncros / 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.38 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm | 327 mm |
| Front Center | 687 mm | 717 mm | 748 mm | 769 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 100.2 mm | 100.2 mm | 100.2 mm | 100.2 mm |
| Stack | 586.1 mm | 586.1 mm | 595.4 mm | 604.6 mm |
| Reach | 395.7 mm | 425.7 mm | 453 mm | 470.3 mm |
| Top Tube Length | 568 mm | 598 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1114 mm | 1144 mm | 1175 mm | 1196 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 731 mm | 739 mm | 753 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Spark 960 belongs to the Scott Spark model. Scott launched 189 bikes of this model so far. You can easily view all of the Scott Spark bikes models from 2017, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit heavier than average, Spark 960 has a weight of 13.7 kg (30.2 lbs). To sum up, it’s 5.55% heavier than the average weight of Trail bikes.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the X-Fusion NUDE Trunnion SCOTT custom w. rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Spark 960 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Spark 960 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
