Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Speedster Disc / D.Butted 6061 Alloy Road geometry / Integrated Headtube
Suspension Fork
Speedster Disc Carbon 1 1/8" carbon steerer
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700-GS 20 Speed
Front Derailleur
Shimano Tiagra FD-4700
Shift Levers
Shimano Tiagra ST-4700 Dual control 20 Speed
Cassette
Shimano CS-HG500 10 Speed 11-32 T
Crank
Shimano Tiagra Compact FC-4700 Hyperdrive 50x34 T
Bottom Bracket
Shimano BB-RS500
Chain
KMC X10
Wheels
Front Hub
Formula Team CL Disc 28 H
Rear Hub
Formula Team CL Disc 28 H
Rims
Syncros Race 22 Disc 28 Front / 28 Rear
Spokes
HTI - Standard Black 2mm
Tires
Schwalbe Lugano 700x28C
Brakes
Brakes
Shimano BR-RS305 Black Mech. Disc160/F and 160/R mm SM-RT54 Rotor
Cockpit
Stem
JD ST92A Alloy 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros RR2.0 Ergonomic 31.8mm
Headset
Integrated Steel Cup
Seat
Saddle
Syncros FL2.5
Seatpost
Syncros RR2.5 31.6/300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.46 mm | 1.5 mm | 1.54 mm | 1.57 mm | 1.59 mm |
| Bottom Bracket Height | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm |
| Front Center | 578 mm | 584 mm | 586 mm | 591 mm | 596 mm | 602 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 44 mm | 45 mm |
| Trail | 72 mm | 69 mm | 63 mm | 60 mm | 57 mm | 56 mm | 55 mm |
| Stack | 518.7 mm | 529.9 mm | 552.5 mm | 573.3 mm | 594.3 mm | 614.5 mm | 633.6 mm |
| Reach | 368.6 mm | 375.5 mm | 379.3 mm | 383.2 mm | 386.6 mm | 391 mm | 399 mm |
| Top Tube Length | 507 mm | 517 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.3 ° | 73.3 ° |
| Head Tube Length | 115 mm | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 985 mm | 991 mm | 993 mm | 999 mm | 1003 mm | 1009 mm | 1024 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 727 mm | 743 mm | 769 mm | 789 mm | 809 mm | 829 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
About this model
Speedster 20 Disc belongs to the Scott Speedster model. 100 bikes variations carry this model name so far. Take a sneak peek at all Scott Speedster bikes models from 2017, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Endurance bikes
The average weight for Endurance bikes is 8.2 kg (18.08 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 10.4 kg (22.93 lbs), the Speedster 20 Disc model is much heavier than average. In conclusion, the average Endurance bike weighs 26.83% less than Speedster 20 Disc.
Speedster 20 Disc components
Fork material
Speedster 20 Disc has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Speedster 20 Disc are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Speedster 20 Disc is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, it won’t be difficult to find the right one for you.
