Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New SUB Cross Alloy 6061 D.B. / Sub Cross Men/Lady geometry / Internal cable routing / SCOTT urban kit ready
Suspension Fork
Suntour Nex HLO / Hyd. Lockout / 63mm travel
Drivetrain
Rear Derailleur
Shimano Deore RD-T610-SGS / Shadow Type / 30Speed
Front Derailleur
Shimano Deore FD-T610 / 34.9mm
Shift Levers
Shimano Deore SL-M610-10 / R-fire plus 2 / w/gear indicator
Cassette
Shimano CS-HG500-10 11-34 T
Crank
Shimano FC-T611 / 48x36x26 / w/CG
Bottom Bracket
Shimano SM-BB52 / 68mm shell
Chain
KMC X10
Pedals
Wellgo M-248DU
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX5058
Rims
Syncros X-20 Disc / 32H / black
Spokes
Stainless black / 14G / 2mm
Tires
Schwalbe Smart Sam / 700x42C / 50 TPI
Brakes
Brakes
Shimano BR-M315 / Hydr. Disc / SM-RT10 CL Rotor / 160F/160R
Brake Levers
Shimano BL-M315
Cockpit
Stem
Syncros UC3.0 / 7° / Black
Handlebar
Syncros UC3.0 / 31.8 / Men: Tbar/620mm/9° bend / Lady: 680mm/15° bend
Headset
GW 1SI110 OE integ.
Seat
Saddle
SUB Cross Men EVO / lady EVO
Seatpost
Syncros UC3.0 / 31.6mm / 350mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 617 mm | 628 mm | 633 mm | 649 mm |
| Reach | 377 mm | 382 mm | 378.9 mm | 386.5 mm |
| Top Tube Length | 553 mm | 568 mm | 578 mm | 593 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 72.3 ° | 72 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 130 mm | 155 mm | 180 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1070 mm | 1081 mm | 1086 mm | 1102 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 682 mm | 687 mm | 698 mm | 705 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sub Cross 20 Lady completes the Scott Sub model. There are 106 bikes that carry this model name. Take a sneak peek at all Scott Sub bikes models from 2017, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Hybrid bikes average weight
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Sub Cross 20 Lady weighs 13.59 kg (29.96 lbs) and is slightly lighter than the average. In short, the average Hybrid bike weight is 1.91% higher than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Sub Cross 20 Lady components
Fork
The Sub Cross 20 Lady comes factory-installed with the SunTour NEX fork. This has a travel range of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Sub Cross 20 Lady model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sub Cross 20 Lady comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
