Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New SUB Cross Alloy 6061 D.B. / Sub Cross Men/Lady geometry / Internal cable routing / SCOTT urban kit ready
Suspension Fork
Suntour Nex HLO / Hyd. Lockout / 63mm travel
Drivetrain
Rear Derailleur
Shimano Deore RD-T610-SGS / Shadow Type / 30 Speed
Front Derailleur
Shimano Deore FD-T610 / 34.9mm
Shift Levers
Shimano Deore SL-M610-10 / R-fire plus 2 / w/gear indicator
Cassette
Shimano CS-HG500-10 11-34 T
Crank
Shimano FC-T611 / 48x36x26 / w/CG
Bottom Bracket
Shimano SM-BB52 / 68mm shell
Chain
KMC X10
Pedals
Wellgo M-248DU
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX5058
Rims
Syncros X-20 Disc / 32H / black
Spokes
Stainless black / 14G / 2mm
Tires
Schwalbe Smart Sam / 700x42C / 50 TPI
Brakes
Brakes
Shimano BR-M315 / Hydr. Disc / SM-RT10 CL Rotor / 160F/160R
Brake Levers
Shimano BL-M315
Cockpit
Stem
Syncros UC3.0 / 7° / Black
Handlebar
Syncros UC3.0 / 31.8 / Men: Tbar/620mm/9° bend / Lady: 680mm/15° bend
Headset
GW 1SI110 OE integ.
Seat
Saddle
SUB Cross Men EVO / lady EVO
Seatpost
Syncros UC3.0 / 31.6mm / 350mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 628 mm | 634 mm | 647 mm | 660 mm | 673 mm |
| Reach | 387.3 mm | 385.8 mm | 392.5 mm | 398.8 mm | 404.6 mm |
| Top Tube Length | 566 mm | 576 mm | 591 mm | 607 mm | 619 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.3 ° | 72 ° | 72 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1077 mm | 1083 mm | 1096 mm | 1109 mm | 1122 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 766 mm | 792 mm | 816 mm | 846 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sub Cross 20 Men is part of the Scott Sub model. 106 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Hybrid bikes average weight
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 13.59 kg (29.96 lbs), Scott bike is slightly lighter than average. In short, the average Hybrid bike weight is 1.91% higher than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
Scott Sub Cross 20 Men 2017 bike is equipped with the SunTour NEX fork, and has 63mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Sub Cross 20 Men are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Sub Cross 20 Men is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
