Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SUB Cross Alloy 6061 D.B. / Sub Cross Men/Lady geometry / Internal cable routing / SCOTT urban kit ready
Suspension Fork
Suntour NEX HLO / Hyd. Lockout / 63mm travel
Drivetrain
Rear Derailleur
Shimano Deore RD-T6000-SGS / Shadow Type / 30Speed
Front Derailleur
Shimano Deore FD-T6010 / 34.9mm
Shift Levers
Shimano Deore SL-M610-10 / R-fire plus 2 / w/gear indicator
Cassette
Shimano CS-HG500-10 11-34 T
Crank
Shimano FC-T6010 / 48x36x26 / w/CG
Bottom Bracket
Shimano SM-BB52 / 68mm shell
Chain
KMC X10-1
Pedals
VP VPE-465
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX5058
Rims
Syncros X-20 Disc / 32H / black
Spokes
15 G / stainless / black
Tires
Schwalbe Smart Sam / 700x42C / 50 TPI
Brakes
Brakes
Shimano BR-M315 / Hydr. Disc / SM-RT10 CL Rotor / 160F/160R
Brake Levers
Shimano BL-M315
Cockpit
Stem
Syncros UC3.0 / 7° / Black
Handlebar
Syncros UC3.0 / 31.8 / Men: Tbar/660mm/9° bend / Lady: 660mm/15° bend
Headset
GW 1SI110 OE integ.
Seat
Saddle
Syncros UC2.5 / UC3.0W
Seatpost
Syncros UC3.0 / 31.6mm / 350mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 628 mm | 634 mm | 647 mm | 660 mm | 673 mm |
| Reach | 387.3 mm | 385.8 mm | 392.5 mm | 398.8 mm | 404.6 mm |
| Top Tube Length | 566 mm | 576 mm | 591 mm | 607 mm | 619 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.3 ° | 72 ° | 72 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1077 mm | 1083 mm | 1096 mm | 1109 mm | 1122 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 766 mm | 792 mm | 816 mm | 846 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sub Cross 20 Men’s is a Scott Sub model. Scott released 106 bikes variations of this model so far. You can easily view all of the Scott Sub bikes models from 2018, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Hybrid bikes
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 13.59 kg (29.96 lbs), the Sub Cross 20 Men’s model is slightly lighter than average. In conclusion, the average Hybrid bike weighs 1.91% more than Sub Cross 20 Men’s.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Scott Sub Cross 20 Men’s 2018 bike is equipped with the SunTour NEX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Sub Cross 20 Men’s bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
