Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New SUB Cross Alloy 6061 / Sub Cross Men/Lady geometry / External cable routing / SCOTT urban kit ready
Suspension Fork
Suntour Nex HLO / Hyd. Lockout / 63mm travel
Drivetrain
Rear Derailleur
Shimano Alivio RD-M4000 / 27 Speed
Front Derailleur
Shimano FD-M370 / 34.9mm
Shift Levers
Shimano SL-M370-9 / R-fire plus / w/gear indicator
Cassette
Shimano CS-HG200-9 11-34 T
Crank
Shimano FC-T3010 / 48x36x26 / w/CG
Bottom Bracket
Shimano BB-UN-26 / Cartridge Type
Chain
KMC X9
Pedals
Wellgo M-141SDU
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX5058
Rims
Syncros X-20 Disc / 32H / black
Spokes
Stainless black / 14G / 2mm
Tires
Impac SmartPac / 700x42C / 50 TPI
Brakes
Brakes
Shimano BR-M315 / Hydr. Disc / SM-RT10 CL Rotor / 160F/160R
Brake Levers
Shimano BL-M315
Cockpit
Stem
Syncros UC3.0 / 7° / Black
Handlebar
Syncros UC3.0 / 31.8 / Men: Tbar/620mm/9° bend / Lady: 680mm/15° bend
Headset
GW 1SI110 OE integ.
Seat
Saddle
SUB Cross Men EVO / lady EVO
Seatpost
Syncros UC3.0 / 31.6mm / 350mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 628 mm | 634 mm | 647 mm | 660 mm | 673 mm |
| Reach | 387.3 mm | 385.8 mm | 392.5 mm | 398.8 mm | 404.6 mm |
| Top Tube Length | 566 mm | 576 mm | 591 mm | 607 mm | 619 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.3 ° | 72 ° | 72 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1077 mm | 1083 mm | 1096 mm | 1109 mm | 1122 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 766 mm | 792 mm | 816 mm | 846 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sub Cross 30 Men is a Scott Sub model. Scott launched 106 bikes of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Hybrid bikes
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 13.94 kg (30.73 lbs), Scott bike is slightly heavier than average. In other words, this model is 0.65% heavier than the average Hybrid bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Scott Sub Cross 30 Men 2017 bike is equipped with the SunTour NEX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Scott Sub Cross 30 Men 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Scott Sub Cross 30 Men has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
