Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sub Cross Alloy 6061 / Sub Cross Men/Lady geometry / External cable routing / SCOTT urban kit ready
Suspension Fork
Zoom 187 D / 63mm travel
Drivetrain
Rear Derailleur
Shimano Altus RD-M370 / 24 Speed
Front Derailleur
Shimano FD-TY710 / 34.9mm
Shift Levers
Shimano SL-M310-8 / R-fire plus / w/gear indicator
Cassette
Shimano CS-HG31-8 11-32 T
Crank
Shimano FC-TY501 / 48x38x28 / w/CG
Bottom Bracket
Shimano BB-UN-100 / Cartridge Type
Chain
KMC Z-7
Pedals
VP VP-536
Wheels
Front Hub
Formula DC-19 FQR disc
Rear Hub
Formula DC-25 RQR disc
Rims
Syncros X-20 Disc / 32H / black
Spokes
14 G / stainless / black
Tires
Impac SmartPac / 700x42C / 50 TPI
Brakes
Brakes
Tektro HDM275 / Hydr. Disc 160F/160R Rotor
Brake Levers
Tektro HDM275
Cockpit
Stem
Syncros UC3.0 / 7° / Black
Handlebar
Syncros UC3.0 / 31.8 / Men: Tbar/660mm/9° bend / Lady: 660mm/15° bend
Headset
GW 1SI110 OE integ.
Seat
Saddle
Syncros UC3.0 / UC3.0W
Seatpost
Syncros UC3.0 / 31.6mm / 350mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 628 mm | 634 mm | 647 mm | 660 mm | 673 mm |
| Reach | 387.3 mm | 385.8 mm | 392.5 mm | 398.8 mm | 404.6 mm |
| Top Tube Length | 566 mm | 576 mm | 591 mm | 607 mm | 619 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.3 ° | 72 ° | 72 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1077 mm | 1083 mm | 1096 mm | 1109 mm | 1122 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 766 mm | 792 mm | 816 mm | 846 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sub Cross 40 Men is part of the Scott Sub model. There are 106 bikes that carry this model name. You can easily view all of the Scott Sub bikes models from 2019, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hybrid bikes average weight
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 13.64 kg (30.07 lbs), the Sub Cross 40 Men model is slightly lighter than average. To sum up, it’s 1.54% lighter than the average weight of Hybrid bikes.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Wheels size
When leaving the production line, the Sub Cross 40 Men model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Sub Cross 40 Men is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
