Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork SunTour NEX -
Groupset Shimano, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sub Sport 6061 Tig welding
Suspension Fork
Suntour NEX-HLO-DS PM 700C / Hyd. Lockout
Drivetrain
Rear Derailleur
Shimano LX-670 10 Speed
Front Derailleur
Shimano Deore FD-T6000
Shift Levers
Shimano Deore SL-T6000
Cassette
Shimano CS-HG500-10 11-34T
Crank
Shimano FC-T670 48x36x26T
Bottom Bracket
Included with crankset
Chain
KMC X10
Pedals
Syncros SP-827
Wheels
Front Hub
Shimano Deore DH-3D37 dynamo CL 32h
Rear Hub
Shimano FH-M3050 32H CL QR * BLACK
Rims
X15 Disc, 32h
Spokes
Pillar Steel 14G
Tires
Schwalbe Citizen 700x47c
Brakes
Brakes
Shimano BR-M200
Brake Levers
Shimano BL-M200
Cockpit
Stem
Syncros UC3.0 adjustable
Handlebar
Syncros UC1.5 680mm / 10° bend
Headset
GW semi integrated
Seat
Saddle
Selle Royal Essenza
Seatpost
Syncros UC3.0 / 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.74 mm | 1.68 mm | 1.62 mm | 1.58 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 640 mm | 653 mm | 668 mm | 678 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 649.7 mm | 649.7 mm | 649.7 mm | 649.7 mm |
| Reach | 373.3 mm | 386.3 mm | 401.3 mm | 411.3 mm |
| Top Tube Length | 566 mm | 579 mm | 594 mm | 604 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 185 mm | 185 mm | 185 mm | 185 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1087 mm | 1100 mm | 1115 mm | 1125 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 784 mm | 800 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Sub Sport 20 Men completes the Scott Sub model. There are 106 bikes that carry this model name. You can easily view all of the Scott Sub bikes models from 2019, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Fitness bikes average weight
On a deeper look, we notice that the average weight of a Fitness bike is 11.24 kg (24.78 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 16.9 kg (37.26 lbs), Scott bike is much heavier than average. In other words, this model is 50.36% heavier than the average Fitness bike.
Overview of components
Fork
The Sub Sport 20 Men comes factory-installed with the SunTour NEX fork. This has a travel range of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Sub Sport 20 Men model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott Sub Sport 20 Men is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
