Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork SunTour NEX -
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SUB Sport 6061 Tig welding
Suspension Fork
Suntour NEX DS PM 700C
Drivetrain
Rear Derailleur
Shimano Alivio RD T4000 9 Speed
Front Derailleur
Shimano Altus FD-M371
Shift Levers
Shimano Altus SL-M2000
Cassette
Shimano CS-HG200-9 11-34T Black
Crank
Shimano Acera FC-T371 Black 48x38x26T
Bottom Bracket
VP-BC73C
Chain
KMC X9
Pedals
VP 856
Wheels
Front Hub
Shimano Deore DH-3D37 dynamo CL 32h
Rear Hub
Shimano FH-TX50 CL 32h
Rims
X12 Disc, 32h
Spokes
Pillar Steel 14G
Tires
Schwalbe Citizen 700x47c
Brakes
Brakes
Shimano BR-M315
Brake Levers
Shimano BL-M315
Cockpit
Stem
Syncros UC3.0 adjustable
Handlebar
Syncros UC1.5 640mm / 10° bend
Headset
GW semi integrated
Seat
Saddle
Syncros Urban Commuter 2.5
Seatpost
Syncros UC3.0 / 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.74 mm | 1.68 mm | 1.62 mm | 1.58 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 640 mm | 653 mm | 668 mm | 678 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 649.7 mm | 649.7 mm | 649.7 mm | 649.7 mm |
| Reach | 373.3 mm | 386.3 mm | 401.3 mm | 411.3 mm |
| Top Tube Length | 566 mm | 579 mm | 594 mm | 604 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 185 mm | 185 mm | 185 mm | 185 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1087 mm | 1100 mm | 1115 mm | 1125 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 784 mm | 800 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sub Sport 20 Men’s is part of the Scott Sub model. Scott launched 106 bikes of this model so far. Take a sneak peek at all Scott Sub bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 17.2 kg (37.92 lbs), Scott bike is much heavier than average. In short, the average Fitness bike weight is 53.02% lower than this one.
Sub Sport 20 Men’s components
Fork
This bike has the SunTour NEX fork installed. The fork’s travel is mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Sub Sport 20 Men’s model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Scott Sub Sport 20 Men’s has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
