Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 190mm -
Fork Fox Float 36
-
Groupset X9, e*thirteen -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Voltage FR Alloy 6061 Hydroformed tubing ISCG & ISCG05 tabs / headtube for 1.5" Dropout with 135x12mm thru axle 190mm travel
Suspension Fork
FOX 36 Air 27.5 180mm travel / Air / RC2
Rear Shock
FOX Float X2 Air Performance Independent high/low comp. and rebound / RVS custom tuned / 241x76mm
Drivetrain
Rear Derailleur
SRAM X9 / short cage / 10 Speed
Front Derailleur
E.thirteen LG-1+ ISCG05 / w/Taco alloy backplate
Shift Levers
SRAM X7 / Trigger Shifter
Cassette
SRAM PG-1050 / 11-36T
Crank
Truvativ Descendant 36T chainring / 170mm
Bottom Bracket
Truvativ BB GXP / Shell 73mm
Chain
KMC X10
Pedals
Wellgo B155U SCT / flat / w/replaceable pins
Wheels
Front Hub
Formula DHL-92 / 110x20mm / thru axle
Rear Hub
Formula DCL-360 135x12mm thru axle / sealed bearings
Rims
Syncros MD27 27.5 Disc / 32H
Spokes
DT Swiss Champion / 2.0 black
Tires
Schwalbe Downhill Evolution Line Front: Magic Mary 27.5x2.35 VertStar Rear: Magic Mary 27.5x2.35 TrailStar Triple Nano Compound / Supergravity
Brakes
Brakes
Shimano XT BR-M8000 Disc 203mm / SM-RT66L Rotor
Brake Levers
Shimano XT BL-M8000
Cockpit
Stem
Syncros XM1.5 35mm / 50mm / 0°
Handlebar
Syncros DH1.5 35mm / 780mm / 20mm Rise Syncros Pro DH dual lock-on grips
Headset
Syncros FR adjustable Semi integrated / adj +-1° or +-2° with cup ID 49.6mm / OD 55mm
Seat
Saddle
Syncros XM2.0 / CrMo Rails
Seatpost
Syncros FR2.0 / 31.6mm / zero offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.48 mm | 1.4 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm |
| Front Center | 741 mm | 776 mm | 801 mm |
| Rake | 52 mm | 52 mm | 52 mm |
| Trail | 116 mm | 116 mm | 116 mm |
| Stack | 625.9 mm | 625.9 mm | 625.9 mm |
| Reach | 387.8 mm | 422.8 mm | 447.8 mm |
| Top Tube Length | 572.4 mm | 607.4 mm | 632.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 368.8 mm | 368.8 mm | 368.8 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1168 mm | 1203 mm | 1228 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm |
| Standover Height | 779 mm | 773 mm | 773 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Voltage FR 710 is part of the Scott Voltage model. Scott released 20 bikes variations of this model so far. Take a sneak peek at all Scott Voltage bikes models from 2017, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Downhill bikes average weight
Downhill bikes have an average weight of 15.89 kg (35.03 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 15.8 kg (34.83 lbs), the Voltage FR 710 model is slightly lighter than average. To sum up, it’s 0.57% lighter than the average weight of Downhill bikes.
Overview of components
Fork
Scott Voltage FR 710 2017 bike is equipped with the Fox Float 36 fork, and has 180mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Scott Voltage FR 710 bike has the FOX Float X2 Air Performance Independent model installed, and has a travel of 190mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Voltage FR 710 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
