Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
134cm - 147cm
XS
134cm - 147cm
SM
145cm - 159cm
SM
145cm - 159cm
MD
157cm - 171cm
MD
157cm - 171cm
LG
169cm - 182cm
LG
169cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed 6061 T6 alloy with tapered headtube, V-Brake
Suspension Fork
VAXA HL 565, 100mm travel, Preload adjust
Drivetrain
Rear Derailleur
Shimano Tourney TY300 7 Speed
Front Derailleur
Shimano Tourney TY300 3 Speed
Shift Levers
Shimano EF41 EZ Fire shifter and rake lever combo, 3x7 Speed
Cassette
Shimano TZ500 14/28T Freewheel
Crank
Surface Alloy, 42/34/24T, Square Taper
Bottom Bracket
BSA 73mm
Chain
PYC P7002
Pedals
PP one piece body with ball bearings and reflectors
Wheels
Front Hub
F: Alloy QR, 100mm OLD
Rear Hub
F: Alloy QR, 100mm OLD
Rims
Surface Alloy Double Wall 32H
Tires
Wanda P1226 2.1" low rolling resistance pattern.
Brakes
Brakes
Alloy V-Brake
Cockpit
Stem
Surface Alloy, Oversize, 60mm x 10 degrees rise
Handlebar
Surface 45mm Riser bar with 9 degrees of sweep, Oversize diameter
Grips
Surface
Headset
Semi-integrated, ZS44/28.6 ZS56/40
Seat
Saddle
Surface Ladies Comfort Recreational, Black Steel rail
Seatpost
Surface Alloy 30.9mm, Integrated Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.62 mm | 1.63 mm | 1.63 mm | 1.51 mm | 1.51 mm | 1.43 mm | 1.43 mm |
| Bottom Bracket Height | 294 mm | 294 mm | 294 mm | 294 mm | 294 mm | 294 mm | 294 mm | 294 mm |
| Stack | 587 mm | 587 mm | 601 mm | 601 mm | 601 mm | 601 mm | 610 mm | 610 mm |
| Reach | 363 mm | 363 mm | 368 mm | 368 mm | 398.5 mm | 398.5 mm | 426 mm | 426 mm |
| Top Tube Length | 536 mm | 536 mm | 546 mm | 546 mm | 576 mm | 576 mm | 606 mm | 606 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 350 mm | 380 mm | 380 mm | 430 mm | 430 mm | 480 mm | 480 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 95 mm | 110 mm | 110 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1052 mm | 1052 mm | 1063 mm | 1063 mm | 1093 mm | 1093 mm | 1124 mm | 1124 mm |
| Bottom Bracket Drop | 61 mm | 80 mm | 61 mm | 80 mm | 61 mm | 80 mm | 61 mm | 80 mm |
| Standover Height | 726 mm | 726 mm | 730 mm | 730 mm | 758 mm | 758 mm | 794 mm | 794 mm |
| Wheels | 27" | 29" | 27" | 29" | 27" | 29" | 27" | 29" |
| Rider Min Height | 134 cm | 134 cm | 145 cm | 145 cm | 157 cm | 157 cm | 169 cm | 169 cm |
| Rider Max Height | 147 cm | 147 cm | 159 cm | 159 cm | 171 cm | 171 cm | 182 cm | 182 cm |
About this model
Splash SE belongs to the Silverback Splash model. Silverback launched 9 bikes of this model so far. Take a sneak peek at all Silverback Splash bikes models from 2023, by clicking here.
Model range prices
Silverback Splash Delight (New Gen) 2023 is the most affordable bike of this model and has a price of 424$. On the other hand, Silverback Splash SX 2023, is the most expensive and costs 1379$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 604$. Doing a quick comparison, we notice that Splash SE price is 215.4% lower than the average cost of a Crosscountry bike.
Overview of components
Wheels size
When it comes to wheels, the Splash SE bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Splash SE comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 134 cm – 182 cm (4.4 ft – 5.97 ft). In short, you can easily find one that suits you.
