silverback Stratos AL SE 2023
2023 Mountain
Estimate price |
2,866$
Weight | 14.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Suntour RAIDON
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
MD
168cm - 180cm
LG
178cm - 192cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium XC/Trail frame based on the award-winning Stratos CF platform. The Stratos AL is designed around 130mm travel front & 105mm rear to provide a little extra comfort with almost no performance trade-off.
Suspension Fork
SR Suntour Raidon 34, 29", 34mm stanchions 15x110mm Thru-axle Boost, 130mm Travel
Rear Shock
Fox Float DPS, P-S, 3 position, EVOL SV
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100, 11 Speed
Shift Levers
R: Shimano Deore SL-M5100-R, 11 Speed
Cassette
Shimano Deore CS-M5100, 11 Speed, 11-51T
Crank
Alloy Crankset, 32T Narrow-Wide, External BB
Bottom Bracket
BSA 73mm
Chain
KMC X11-1, 11 Speed
Pedals
Not Included
Wheels
Front Hub
F: Alloy, 32H, 15x110mm Thru-Axle, 6 bolt
Rear Hub
F: Alloy, 32H, 15x110mm Thru-Axle, 6 bolt
Rims
F: SURFACE 29"; Asymmetrical Alloy Rim, Tubeless Ready
Tires
Maxxis Rekon Race, 29x2.35", 120tpi, EXO, Tubeless
Brakes
Brakes
Tektro Hydraulic Disc
Cockpit
Stem
SURFACE Alloy, 31.8mm, Rise 6°
Handlebar
SURFACE Alloy, Dia: 31,8mm, 760mm, 9° Backsweep, 20mm Rise
Grips
SURFACE Enduro
Headset
Steel Semi-Integrated, ZS44/28.6 ZS56/40
Seat
Saddle
SURFACE
Seatpost
SURFACE Dropper with Lever, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.34 mm | 1.3 mm | 1.27 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Stack | 596 mm | 606 mm | 615 mm | 624 mm |
| Reach | 432 mm | 452 mm | 472 mm | 492 mm |
| Top Tube Length | 579 mm | 601 mm | 624 mm | 646 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 430 mm | 480 mm | 510 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1151 mm | 1175 mm | 1199 mm | 1223 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Standover Height | 782 mm | 784 mm | 787 mm | 802 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 168 cm | 178 cm | 188 cm |
| Rider Max Height | 170 cm | 180 cm | 192 cm | 200 cm |
Model Overview
Stratos AL SE completes the Silverback Stratos model. 23 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Silverback Stratos AL Comp MS 2023 has a starting price of 2016$. Silverback Stratos CF SBC 2023 on the other hand is the most expensive at 6582$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2653$. Doing a quick comparison, we notice that Stratos AL SE price is 4.11% lower than the average cost of a Trail bike.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.88 kg (28.4 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably heavier than average, Stratos AL SE has a weight of 14.4 kg (31.75 lbs). In other words, this model is 11.8% heavier than the average Trail bike.
Overview of components
Fork
The Suntour RAIDON is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the Fox Float DPS model, with a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the Stratos AL SE bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Silverback Stratos AL SE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Stratos AL SE comes in 4 sizes, that range from 154 cm – 200 cm (5.05 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Stratos AL SE. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
