Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 Di2 -
Suspension Rigid -
Battery Mahle EbikeMotion X20 236Wh ONE Remote -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kiaro Pmax, Cosmic Red Glossy, 46cm
Drivetrain
Rear Derailleur
Shimano 105 Disc Di2
Shift Levers
Shimano 105 Disc Di2
Cassette
Cassette Shimano 105 11-34
Crank
Crankset Shimano 105 50/34 172,5mm
Wheels
Rims
Mavic Cosmic SL 45-Mahle X20-PRO ONE AddixRace,28-622
Brakes
Brakes
Shimano 105 Disc Di2
Cockpit
Stem
Zero III 130mm x 12°
Handlebar
Simplon ERG Carbon 38cm
Headset
Acros AiX-344
Seat
Saddle
Selle Italia DIVA FLOW black
Seatpost
CARBON ROD SL II 27.2x400mm 0mm setback
Motor & Battery
Battery
Mahle EbikeMotion X20 236Wh ONE Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.5 mm | 1.52 mm | 1.56 mm | 1.57 mm | 1.59 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 590 mm | 593 mm | 589 mm | 602 mm | 618 mm | 633 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 66 mm | 47 mm | 47 mm | 48 mm | 49 mm |
| Stack | 525 mm | 545 mm | 567 mm | 591 mm | 611 mm | 633 mm |
| Reach | 355 mm | 364 mm | 373 mm | 379 mm | 390 mm | 399 mm |
| Top Tube Length | 503 mm | 530 mm | 545 mm | 559 mm | 576 mm | 591 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 550 mm |
| Head Tube Angle | 69 ° | 70 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 136 mm | 151 mm | 176 mm | 195 mm | 216 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 984 mm | 988 mm | 983 mm | 997 mm | 1013 mm | 1028 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 702 mm | 731 mm | 751 mm | 772 mm | 791 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Kiaro Pmax 105 Di2 is a Simplon Kiaro model. Simplon launched 24 bikes of this model so far. Take a sneak peek at all Simplon Kiaro bikes models from 2023, by clicking here.
Model range prices
Simplon Kiaro Disc Shimano 105 DI2 2023 is the most economical model, with a starting price of 4989$. Simplon Kiaro Pmax DuraAce-24 Di2 2023 on the other hand costs 9555$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 7113$. Comparing this to the average Endurance bike price, we see that the price is 203.2% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Kiaro Pmax 105 Di2 model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Simplon Kiaro Pmax 105 Di2 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
