simplon Rapcon PMax XX1 Eagle AXS 2023
2023 E-bike
Estimate price |
10,666$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Fork Fox Factory Float 38
-
Groupset XX1 Eagle AXS, FSA -
Suspension Full, Electronic -
Motor Bosch 250W 85Nm mid-drive -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
FOX 38 FLOAT 29 FACTORY 150mm LV
Rear Shock
Fox Float LIVE VALVE Factory 205x60mm
Drivetrain
Shift Levers
SRAM XX1 Eagle AXS
Crank
FSA CK-745 alloy für Bosch Gen. 4 170mm
Bottom Bracket
Bosch, press-fit
Wheels
Rims
Mavic E-Deemax-Schwalbe Nobby Nic 62-622
Tires
Schwalbe Nobby Nic 29x2.4"; Super Ground
Brakes
Brakes
SRAM Code RSC;4-Kolben (pistons);220mm;200mm
Cockpit
Stem
Simplon ZERO II 50mm x 17°
Handlebar
Simplon CARBON RISER 760
Grips
Simplon Shark Lock
Seat
Saddle
w/o saddle
Seatpost
Kindshock LEV Integra 31.6, 125mm travel
Motor & Battery
Motor
Bosch Performance Line CX + Power T. 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.32 mm | 1.27 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 732 mm | 754 mm | 791 mm | 827 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 112 mm | 110 mm | 111 mm |
| Stack | 611 mm | 616 mm | 629 mm | 643 mm |
| Reach | 427 mm | 447 mm | 477 mm | 507 mm |
| Top Tube Length | 578 mm | 599 mm | 632 mm | 665 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 95 mm | 110 mm | 125 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1197 mm | 1219 mm | 1256 mm | 1292 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 767 mm | 773 mm | 773 mm | 773 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Rapcon PMax XX1 Eagle AXS is part of the Simplon E Rapcon model. 8 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Simplon Rapcon PMax GX1 Eagle 2023 is the cheapest e-bike model and costs 8493$. Simplon Rapcon PMax XX1 Eagle AXS 2023 is the most expensive one and costs 9874$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 9874$. Doing a quick comparison, we notice that Rapcon PMax XX1 Eagle AXS price is 106.35% higher than the average cost of an Enduro e-bike.
Rapcon PMax XX1 Eagle AXS components
Fork
The Fox Factory Float 38 is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Rapcon PMax XX1 Eagle AXS model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rapcon PMax XX1 Eagle AXS has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Rapcon PMax XX1 Eagle AXS comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Simplon model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
