Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized E5 Premium Aluminum, fully manipulated tubing w/ smooth welds, 1-1/8"" lower bearing
Suspension Fork
Specialized A1 Premium Aluminum
Drivetrain
Rear Derailleur
Shimano Claris 2400
Front Derailleur
Shimano Claris 2400
Shift Levers
Shimano Claris 2400 STI
Cassette
Sunrace, 8-speed, 11-32
Crank
Shimano Claris, 50/34
Bottom Bracket
Shimano, Octalink spline
Chain
KMC Z51, 8-speed
Pedals
Nylon flat test ride, loose-ball, w/ reflectors
Wheels
Rims
AXIS Classic
Tires
Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
Brakes
Brakes
Tektro, caliper, dual pivot, cartridge pads
Cockpit
Stem
Specialized 3D forged alloy, 4-bolt, 6-degree rise
Handlebar
Specialized, shallow drop, alloy, 125mm drop, 70mm short-reach
Headset
1-1/8"" integrated sealed Cr-Mo cartridge bearings, 20mm alloy cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Toupé Sport, hollow Cr-Mo rails, 143mm
Seatpost
Specialized Sport, alloy, 2-bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.37 mm | 1.42 mm | 1.47 mm | 1.54 mm | 1.59 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 578 mm | 578 mm | 583 mm | 593 mm | 607 mm | 613 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 43 mm |
| Trail | 63 mm | 58 mm | 58 mm | 55 mm | 55 mm | 52 mm |
| Stack | 498 mm | 519 mm | 540 mm | 566 mm | 599 mm | 624 mm |
| Reach | 379 mm | 379 mm | 379 mm | 384 mm | 389 mm | 393 mm |
| Top Tube Length | 512 mm | 530 mm | 540 mm | 557 mm | 575 mm | 593 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 145 mm | 170 mm | 205 mm | 230 mm |
| Chainstay Length | 397 mm | 399 mm | 399 mm | 399 mm | 402 mm | 402 mm |
| Wheelbase | 964 mm | 966 mm | 972 mm | 982 mm | 1000 mm | 1006 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 728 mm | 751 mm | 775 mm | 797 mm | 826 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Allez is a Specialized Allez model. 112 bikes variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Allez components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Allez model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Allez has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Allez comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
