Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, fully manipulated tubing, smooth weld, compact race design, integrated headset
Suspension Fork
Specialized FACT carbon legs, aluminum crown and steerer
Drivetrain
Rear Derailleur
Shimano 2300
Front Derailleur
Shimano 2300
Shift Levers
Shimano 2300 STI
Cassette
Shimano HG-50, 8-speed, 13-26t
Crank
Shimano 2300 compact
Bottom Bracket
Cr-Mo axle, 68mm x 113mm
Chain
KMC Z-51 nickel plate
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Front Hub
Forged aluminum, sealed bearing, QR, 32h
Rear Hub
Forged aluminum, double-sealed, cassette, QR, 32h
Rims
Alex S480, 32h
Spokes
Stainless 14g
Tires
Specialized Espoir Sport w/ double BlackBelt, 60 TPI, wire bead, 700x23c
Brakes
Brakes
Tektro forged alloy, dual Teflon pivot
Cockpit
Stem
Alloy, CP bolt,12-degree, 31.8mm
Handlebar
New Specialized Tarmac Comp, alloy
Headset
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Riva Road
Seatpost
New Specialized Sport, alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.38 mm | 1.43 mm | 1.48 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 576 mm | 583 mm | 591 mm | 605 mm | 613 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 57 mm | 57 mm | 56 mm | 56 mm | 53 mm |
| Stack | 497 mm | 519 mm | 540 mm | 567 mm | 599 mm | 624 mm |
| Reach | 377 mm | 377 mm | 377 mm | 384 mm | 389 mm | 394 mm |
| Top Tube Length | 510 mm | 529 mm | 540 mm | 557 mm | 574 mm | 592 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 145 mm | 170 mm | 205 mm | 230 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 399 mm | 402 mm |
| Wheelbase | 962 mm | 962 mm | 970 mm | 978 mm | 995 mm | 1005 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 729 mm | 769 mm | 790 mm | 808 mm | 828 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Allez Compact is part of the Specialized Allez model. Specialized launched 112 bikes of this model so far. Take a sneak peek at all Specialized Allez bikes models from 2012, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Allez Compact components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Allez Compact 2012 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Allez Compact comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
