Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, fully manipulated tubing, smooth weld compact race design, integrated headset
Suspension Fork
Specialized FACT carbon, carbon fiber legs, aluminum crown and steerer
Drivetrain
Rear Derailleur
Shimano Tiagra, short cage
Front Derailleur
Shimano Sora, 31.8mm clamp, bottom pull
Shift Levers
Shimano Sora, 9-speed STI, flight deck compatible
Cassette
Shimano Tiagra, 9-speed, 11-25t
Crank
Sugino, five arm, polished
Bottom Bracket
Sealed cartridge, square taper, 68mm x 103mm
Chain
Shimano HG73, 9-speed
Pedals
Silver cage, black body, w/ toe clip and strap
Wheels
Front Hub
Specialized forged alloy, 32h, sealed bearings, QR
Rear Hub
Specialized forged alloy, 32h, double sealed bearings, cassette, QR
Rims
Alex S500, sleeve joint, CNC sidewalls, 32h
Spokes
Stainless 14g
Tires
Specialized Mondo Sport, 700x23c, wire bead, 60TPI, Flak Jacket
Brakes
Brakes
Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
Brake Levers
Shimano Sora, 9-speed STI, flight deck compatible
Cockpit
Stem
Specialized Comp-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
Handlebar
Specialized Comp, 6061 alloy, short drop, ergonomic shaping, 31.8mm
Headset
Specialized Mindset, 1-1/8"" integrated threadless, steel cage bearings, 20mm alloy cone with one 10mm and two 5mm alloy spacers
Seat
Saddle
Specialized Comp Road, full padding
Seatpost
Specialized carbon wrapped, two-bolt clamp, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 58cm | 61cm | 56cm | 54cm | 49cm | 52cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 0.93 mm | 0.97 mm | 0.92 mm | 0.91 mm | 0.83 mm | 0.9 mm |
| Bottom Bracket Height | 262 mm | 263 mm | 263 mm | 263 mm | 264 mm | 263 mm |
| Front Center | 205 mm | 230 mm | mm | mm | mm | mm |
| Stack | 547 mm | 587 mm | 527 mm | 507 mm | 437 mm | 487 mm |
| Reach | 589 mm | 607 mm | 572 mm | 555 mm | 525 mm | 544 mm |
| Seat Tube Angle | 56 ° | 59 ° | 59 ° | 60 ° | 60 ° | 65 ° |
| Seat Tube Length | 407 mm | 410 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 72 mm | 71 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Allez Double completes the Specialized Allez model. There are 112 bikes that carry this model name. You can easily view all of the Specialized Allez bikes models from 2009, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Allez Double model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Allez Double has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
