Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized Allez A1 Premium aluminum, fully manipulated tubing, smooth weld compact race design, integrated headset
Suspension Fork
Allez carbon, carbon fiber legs, aluminum crown and steerer
Drivetrain
Rear Derailleur
Shimano 2300
Front Derailleur
Shimano 2300
Shift Levers
Shimano 2300 STI, flight deck compatible
Cassette
Shimano HG-50, 8-speed, 12-25t
Crank
Shimano 2300
Bottom Bracket
Cr-Mo axle, 68mm x 113mm
Chain
KMC Z-51
Pedals
Silver cage/black body, w/ black toe clips and strap
Wheels
Front Hub
Forged aluminum, sealed, QR, 32h
Rear Hub
Forged aluminum, double-sealed, cassette, QR, 32h
Rims
Alex S500, aluminum, sleeve joint, CNC machined sidewalls
Spokes
Stainless 14g
Tires
Specialized Mondo Sport, 700x23c, wire bead, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Light dual pivot brake, Teflon pivots, forged alloy, w/ standard pads
Brake Levers
Shimano 2300 STI, flight deck compatible
Cockpit
Stem
Alloy, CP bolt, 31.8mm
Handlebar
Specialized Elite, 6061 aluminum, short drop, 31.8mm
Headset
Cage bearings integrated w/ headset, 20mm of spacers w/ top cap
Seat
Saddle
Body Geometry Rival road, w/ steel rails
Seatpost
Alloy, two-bolt clamp, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 580 mm | 580 mm | 587 mm | 595 mm | 610 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 65 mm | 60 mm | 60 mm | 59 mm | 59 mm | 56 mm |
| Top Tube Length | 514 mm | 533 mm | 544 mm | 561 mm | 578 mm | 596 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 500 mm | 520 mm | 540 mm | 580 mm |
| Head Tube Angle | 71.75 ° | 72.5 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 155 mm | 180 mm | 205 mm | 230 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 403 mm | 406 mm |
| Wheelbase | 970 mm | 971 mm | 978 mm | 987 mm | 1004 mm | 1014 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 718 mm | 751 mm | 773 mm | 796 mm | 818 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Allez Double is part of the Specialized Allez model. Specialized released 112 bikes variations of this model so far. Take a sneak peek at all Specialized Allez bikes models from 2010, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Allez Double components
Fork material
Allez Double has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Allez Double model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Specialized Allez Double bike has 6 sizes, in the range of 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
