Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New Specialized E5 Premium Aluminum w/ D'Aluisio Smartweld Technology, 1-1/8"" lower bearing, threaded BB
Suspension Fork
Specialized FACT carbon, alloy crown/steerer
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra STI
Cassette
Shimano Tiagra, 10-speed, 12-28
Crank
Shimano Tiagra, 50/34
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC X10, 10-speed, reusable Missing Link
Pedals
Nylon flat test ride, loose-ball, w/ reflectors
Wheels
Rims
AXIS Classic
Tires
Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
Brakes
Brakes
AXIS 1.0
Cockpit
Stem
Specialized 3D forged alloy, 4-bolt, 6-degree rise
Handlebar
Specialized, shallow drop, alloy, 125mm drop, 70mm short-reach
Headset
1-1/8"" integrated sealed Cr-Mo cartridge bearings, 20mm alloy cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Toupé Sport, hollow Cr-Mo rails, 143mm
Seatpost
Specialized Sport, alloy, 2-bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.38 mm | 1.42 mm | 1.46 mm | 1.52 mm | 1.58 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 578 mm | 579 mm | 583 mm | 593 mm | 610 mm | 612 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61 mm | 57 mm | 59 mm | 56 mm | 56 mm | 52 mm |
| Stack | 520 mm | 522 mm | 539 mm | 565 mm | 597 mm | 623 mm |
| Reach | 372 mm | 379 mm | 379 mm | 387 mm | 394 mm | 394 mm |
| Top Tube Length | 509 mm | 531 mm | 541 mm | 560 mm | 579 mm | 593 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 125 mm | 125 mm | 145 mm | 170 mm | 205 mm | 230 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 399 mm | 402 mm |
| Wheelbase | 964 mm | 965 mm | 969 mm | 980 mm | 999 mm | 1005 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 734 mm | 739 mm | 761 mm | 783 mm | 809 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Allez Elite completes the Specialized Allez model. There are 112 bikes that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
According to our math, the average price for a trustworthy Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Allez Elite components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Allez Elite model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Specialized Allez Elite bike has 6 sizes, in the range of 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
