Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized Allez A1 Premium aluminum, fully manipulated tubing, smooth weld compact race design, integrated headset
Suspension Fork
Allez carbon, carbon fiber legs, aluminum crown and steerer
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 STI, flight deck compatible
Cassette
Shimano 105, 10-speed, 12-27t
Crank
Shimano FC-R600
Bottom Bracket
With Crankset
Chain
KMC DX10 SC
Pedals
Silver cage/black body, w/ black toe clips and strap
Wheels
Front Hub
Forged aluminum, 32h sealed ball bearings, QR
Rear Hub
Forged aluminum, 32h double sealed ball bearings, cassette, QR
Rims
Mavic CXP-22 N, aluminum triple-wall, sleeve joint, CNC machined sidewalls
Spokes
Stainless 14g
Tires
Specialized Mondo Sport, 700x23c, wire bead, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Tektro cold-forged alloy, dual pivot brake w/ cartridge pads
Brake Levers
Shimano 105 STI, flight deck compatible
Cockpit
Stem
Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
Handlebar
Specialized Comp Ergo, 6061 alloy
Headset
Cage bearings integrated w/ headset, 20mm of spacers w/ top cap
Seat
Saddle
Body Geometry Rival road, w/ Cr-Mo rails
Seatpost
Carbon wrapped, two-bolt clamp, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 580 mm | 580 mm | 587 mm | 595 mm | 610 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 65 mm | 60 mm | 60 mm | 59 mm | 59 mm | 56 mm |
| Top Tube Length | 514 mm | 533 mm | 544 mm | 561 mm | 578 mm | 596 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 500 mm | 520 mm | 540 mm | 580 mm |
| Head Tube Angle | 71.75 ° | 72.5 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 155 mm | 180 mm | 205 mm | 230 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 403 mm | 406 mm |
| Wheelbase | 970 mm | 971 mm | 978 mm | 987 mm | 1004 mm | 1014 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 718 mm | 751 mm | 773 mm | 796 mm | 818 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Allez Elite Compact is a Specialized Allez model. There are 112 bikes that carry this model name. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
Allez Elite Compact has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Allez Elite Compact 2010 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Allez Elite Compact is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Allez Elite Compact comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
