Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized Allez A1 Premium aluminum, fully manipulated tubing, smooth weld compact race design, integrated headset
Suspension Fork
Allez carbon, carbon fiber legs, aluminum crown and steerer
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora STI, flight deck compatible
Cassette
Shimano HG-50, 9-speed, 12-25t
Crank
Shimano FC-R453
Bottom Bracket
Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm x 118mm
Chain
KMC X9 w/ reuseable Missing Link
Pedals
Silver cage/black body, w/ black toe clips and strap
Wheels
Front Hub
Forged aluminum, 32h, sealed ball bearings, QR
Rear Hub
Forged aluminum, 32h, double sealed ball bearings, cassette, QR
Rims
Alex S500, aluminum, sleeve joint, CNC machined sidewalls
Spokes
Stainless 14g
Tires
Specialized Mondo Sport, 700x23c, wire bead, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Light dual pivot brake, Teflon pivots, forged alloy, w/ standard pads
Brake Levers
Shimano Sora STI, flight deck compatible
Cockpit
Stem
Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
Handlebar
Specialized Comp Ergo, 6061 alloy
Headset
Cage bearings integrated w/ headset, 20mm of spacers w/ top cap
Seat
Saddle
Body Geometry Rival road, w/ steel rails
Seatpost
Alloy, two-bolt clamp, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 580 mm | 580 mm | 587 mm | 595 mm | 610 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 65 mm | 60 mm | 60 mm | 59 mm | 59 mm | 56 mm |
| Top Tube Length | 514 mm | 533 mm | 544 mm | 561 mm | 578 mm | 596 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 500 mm | 520 mm | 540 mm | 580 mm |
| Head Tube Angle | 71.75 ° | 72.5 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 155 mm | 180 mm | 205 mm | 230 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 403 mm | 406 mm |
| Wheelbase | 970 mm | 971 mm | 978 mm | 987 mm | 1004 mm | 1014 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 718 mm | 751 mm | 773 mm | 796 mm | 818 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Allez Sport Triple belongs to the Specialized Allez model. 112 bikes variations carry this model name so far. Take a sneak peek at all Specialized Allez bikes models from 2010, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Allez Sport Triple are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
