Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 SL Premium Aluminum, Fitness Geometry, fully-manipulated butted tubing, internal cable routing, flat mount disc, rack & Plug + Play mounts
Drivetrain
Rear Derailleur
Shimano Altus, 8-speed
Front Derailleur
Shimano Tourney, top swing, for 7-/8-speed 31.8mm clamp
Shift Levers
Shimano Altus, 8-speed
Cassette
Sunrace, 8-speed, 11-34t
Crank
Stout, forged alloy, 48/38/28T w/chainguard
Bottom Bracket
BSA, square taper, cartridge bearings
Chain
KMC X8, 8-speed w/reusable MissingLink
Pedals
Specialized Fitness platform
Wheels
Front Hub
Specialized disc, double-sealed, loose ball bearings, 9mm QR
Rear Hub
Specialized disc, loose ball bearings, for Shimano 8-/9-speed cassettes, 9mm QR
Rims
700c disc, 6061 aluminum double-wall
Spokes
Stainless, 14g
Tires
Trigger Sport Reflect, 700x38mm, 60TPI, wire bead
Brakes
Brakes
Tektro Flow Set Control, hydraulic disc, metal pads, post mount, 160mm rotor
Cockpit
Stem
3D forged aluminum, 7-degree rise, 31.8mm clamp
Handlebar
Specialized, double-butted alloy, 9-degree backsweep, 31.8mm
Grips
Body Geometry Flow Set Control Grips, lock-on
Seat
Saddle
Aldia Sport, steel rails, 155mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.52 mm | 1.52 mm | 1.52 mm |
| Front Center | 613 mm | 630 mm | 641 mm | 659 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 586 mm | 600 mm | 617 mm | 636 mm |
| Reach | 384 mm | 396 mm | 406 mm | 418 mm |
| Top Tube Length | 561 mm | 578 mm | 593 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 375 mm | 425 mm | 475 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1057 mm | 1073 mm | 1084 mm | 1102 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 703 mm | 731 mm | 764 mm | 796 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Ariel Disc belongs to the Specialized Ariel model. There are 45 bikes that carry this model name. Take a sneak peek at all Specialized Ariel bikes models from 2017, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Ariel Disc components
Wheels size
As for the wheels, Specialized Ariel Disc 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ariel Disc has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
