Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ariel A1 Premium Aluminum, low standover women's geometry frame, forged dropouts w/ replaceable hanger, integrated kickstand mount
Suspension Fork
SR SunTour SF10-NVX-MLO 700C, alloy lower, 75mm travel, 28mm stanchions, coil spring, mechanical lock-out
Drivetrain
Rear Derailleur
Shimano Acera, 8-speed
Front Derailleur
Shimano FD-C051BM, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano SL-MC40, 8-speed, rapid fire
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
Shimano FC-M361-8 w/ chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z8, w/ reusable Missing Link
Pedals
Composite platform body, sealed loose ball bearings
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR
Rear Hub
Forged alloy, double sealed, ground race, cassette, QR, 32h
Rims
Alex Crosstrail, 700c, alloy double wall w/ machine sidewalls, 32h
Spokes
1.8mm (15g) stainless
Tires
Specialized Borough XC Sport 700x45c, 60TPI, wire bead
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
V-Brake, Linear pull
Cockpit
Stem
Melt Forged alloy, 2-bolt, 25.4mm, 15 degree rise
Handlebar
Alloy riser bar, 25.4mm, 25mm rise, 620mm wide, 8 degree back sweep, 8 degree up
Grips
Specialized Myka, closed end, 130mm
Headset
1-1/8"" threadless, sealed loose ball bearings
Seat
Saddle
Specialized Body Geometry XC women's, front and rear bumpers, 155mm width
Seatpost
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 643 mm | 649 mm | 664 mm | 668 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Trail | 88 mm | 88 mm | 88 mm | 85 mm |
| Top Tube Length | 573 mm | 578 mm | 593 mm | 608 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1088 mm | 1094 mm | 1109 mm | 1113 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 696 mm | 735 mm | 773 mm | 810 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Ariel Sport completes the Specialized Ariel model. Specialized launched 45 bikes of this model so far. Take a sneak peek at all Specialized Ariel bikes models from 2010, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
Our math shows that the average cost of a dependable Fitness bike is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Ariel Sport components
Fork
The Ariel Sport comes factory-installed with the SunTour fork. This has a travel range of 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Ariel Sport bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Ariel Sport is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Ariel Sport comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
