Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 160mm -
Fork Marzocchi Bomber Z1
-
Groupset X7, X5 -
Suspension Full -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BigHit FSR, M4 tubing ORE TT/DT, full cartridge bearing pivots, ISCG mount, asymetrical rear triangle, 6.8"" travel
Suspension Fork
Marzocchi Z1 Sport for SBC, 160mm travel, coil spring, rebound adj. 20mm thru-axle, alloy steerer tube
Rear Shock
Xfusion Vector R coil over, adj rebound, Spring rate S: 450, M: 500, L: 550 8.5x2.25""
Drivetrain
Rear Derailleur
SRAM X-7, 9-speed, short cage
Shift Levers
SRAM X5 trigger
Cassette
SRAM PG-830, 8-speed, 11-32t
Crank
Truvativ Ruktion, 170mm w/ SBC chain guide
Bottom Bracket
Truvativ Howitzer XR, oversize sealed outboard cartridge bearing, 73mm shell
Chain
KMC X8 w/ reuseable Missing Link
Pedals
Alloy platform, 9/16""
Wheels
Front Hub
Hi-Lo disc, 20mm thru-axle, 36h
Rear Hub
Disc, Bolt-on, 135mm, 36h
Rims
P-Disc, 32mm, 36h
Spokes
14g stainless
Tires
Specialized Clutch SX 26x2.3"", 60 TPI, aramid bead, soft dual compound
Brakes
Brakes
Avid Juicy 3 full hydraulic, metallic brake pads, 203mm rotor
Brake Levers
Avid Juicy 3 Hydraulic
Cockpit
Stem
Specialized Aggro stem, 35mm extension, OS 31.8, 4-bolt, forged
Handlebar
6061 Alloy DH low rise bar, 31.8mm bar, 750mm wide, 9 degree backsweep, 6 degree up
Grips
Specialized waffle grip
Headset
Tank FX, 1-1/8"" threadless, Cr-Mo lower cup, std upper cup
Seat
Saddle
Specialized Enduro, 8mm steel rails
Seatpost
6061 butted alloy, two bolt no offset, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 365 mm | 365 mm | 365 mm |
| Stack | 589 mm | 589 mm | 589 mm |
| Reach | 398 mm | 421 mm | 443 mm |
| Top Tube Length | 557 mm | 580 mm | 602 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 394 mm | 419 mm | 458 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1156 mm | 1179 mm | 1201 mm |
| Bottom Bracket Drop | -22 mm | -22 mm | -22 mm |
| Standover Height | 752 mm | 757 mm | 744 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
BigHit FSR I belongs to the Specialized Bighit model. There are 9 bikes that carry this model name. You can easily view all of the Specialized Bighit bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
BigHit FSR I components
Fork
The Marzocchi Bomber Z1 is included from the factory. It has a travel distance of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The wheels on BigHit FSR I are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The BigHit FSR I has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
BigHit FSR I comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
