Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 110mm -
Travel Rear 110mm -
Fork RockShox Revelation RC
-
Groupset X1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 9m carbon front triangle, 29"" geometry, FACT IS construction, M5 alloy rear triangle, tapered headtube, carbon PF30 BB, full internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 110mm travel
Suspension Fork
RockShox Revelation RC 29, tapered alloy steerer, w/ lockout, compression, rebound adjust, 15mm thru-axle, 110mm travel
Rear Shock
Custom FOX Float CTD Performance w/ AUTOSAG, Climb, Trail, Descend settings, rebound adjust, 197x48mm
Drivetrain
Rear Derailleur
SRAM X1, 11-speed, alloy cage
Shift Levers
SRAM X1, 11-speed, trigger
Cassette
SRAM XG 1180, 11-speed, 10-42
Crank
SRAM X1 1000, X SYNC ring, PF30, 30T, 94mm BCD spider
Bottom Bracket
SRAM, PF30, OS press-in bearings, sealed cartridge
Pedals
Resin test ride, w/ toe clips, CEN std.
Wheels
Front Hub
Roval Control 29, 15mm thru-axle, 32h
Rear Hub
Roval Control 29 142+, 12mm thru-axle, 32h
Rims
Roval Control 29, alloy, 21mm inner width, 32h
Spokes
DT Swiss Revolution
Tires
Specialized Ground Control, 60TPI, 2Bliss Ready, folding bead, 29x2.3""
Brakes
Brakes
Shimano SLX BR-M675, hydraulic disc, metallic pads, S/M: 180mm rotor, Others: 200mm
Brake Levers
Shimano SLX BL-M675, hydraulic, alloy lever
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise
Handlebar
Specialized XC, mini rise, 7050 alloy, 8-backsweep, 6-upsweep, 10mm rise, 31.8mm
Grips
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL
Headset
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
Seatpost
Command Post IR, 3-position height adjustable, alien head design, bottom mount cable routing, w/ remote adjust SRL, 30.9mm, 100mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.41 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 585 mm | 594 mm | 618 mm | 641 mm |
| Reach | 394 mm | 422 mm | 439 mm | 460 mm |
| Top Tube Length | 549 mm | 581 mm | 606 mm | 636 mm |
| Seat Tube Angle | 75 ° | 74.8 ° | 74.5 ° | 74.2 ° |
| Seat Tube Length | 394 mm | 430 mm | 468 mm | 523 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 90 mm | 100 mm | 125 mm | 150 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1094 mm | 1125 mm | 1150 mm | 1180 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 734 mm | 739 mm | 743 mm | 754 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Camber Elite Carbon 29 completes the Specialized Camber model. Specialized launched 60 bikes of this model so far. Take a sneak peek at all Specialized Camber bikes models from 2015, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Camber Elite Carbon 29 components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 110mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The shock that’s installed on this bike is Custom FOX Float CTD Performance w/ AUTOSAG, with a travel distance of 110mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the Camber Elite Carbon 29 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Camber Elite Carbon 29 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Camber Elite Carbon 29 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Specialized Camber Elite Carbon 29 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
