Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum, ground control geometry, 700c low entry comfort frame, formed tubes w/ integrated kickstand mount, forged dropouts w/ replaceable hanger
Suspension Fork
SR Suntour NEX-4110V2, 63mm travel, 1pc. alloy lower, Hi-Ten stanchions and steerer, coil/mcu w/ preload adjust, spring assisted seals
Drivetrain
Rear Derailleur
Shimano Altus, 7-speed
Front Derailleur
Shimano FD-C051BM, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano Revo, 7-speed, twist shifter
Cassette
Shimano MF-TZ31-7, 7-speed, 13-34t Mega Range
Crank
Shimano FCM-151 w/ chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z7 w/ reuseable Missing Link
Pedals
Comfort pedal, composite body w/rubber top, sealed loose ball bearings
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR
Rear Hub
Forged alloy, double sealed, ground race, freewheel type, QR
Rims
700c, single wall, 32h
Spokes
2mm (14g) stainless
Tires
Specialized Hemisphere, 700x38c, 60TPI, wire bead w/ Flak Jacket protection
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
Alloy 4-finger, kraton lever pad, for twist shifter
Cockpit
Stem
Ground control, 4-bolt, alloy head/Cr-Mo quill, 25.4mm clamp
Handlebar
Hi-Ten Comfort riser bar, 25.4mm, 60mm rise, 620mm wide, 15 degree back sweep, 5 degree up
Headset
1-1/8"" threaded, sealed loose ball bearings
Seat
Saddle
Comfort Plus with dual density foam and springs for extra comfort
Seatpost
Alloy suspension, 2-bolt head, 27.2mm w/ 3.8mm spring
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Front Center | 641 mm | 644 mm |
| Rake | 40 mm | 40 mm |
| Trail | 89 mm | 89 mm |
| Top Tube Length | 604 mm | 619 mm |
| Seat Tube Angle | 70 ° | 69 ° |
| Seat Tube Length | 370 mm | 425 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 504 mm | 504 mm |
| Wheelbase | 1136 mm | 1138 mm |
| Bottom Bracket Drop | 73 mm | 73 mm |
| Standover Height | 461 mm | 459 mm |
| Wheels | 700 | 700 |
About this model
Carmel 700 3 Low Entry is part of the Specialized Carmel model. Specialized released 16 bikes variations of this model so far. Check out the entire range from 2010 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Comfort bikes
If you want an acceptable Comfort bike you should know that the average price is 360$. However, you could also get a good Comfort bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Carmel 700 3 Low Entry components
Fork
The SunTour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the Carmel 700 3 Low Entry bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Carmel 700 3 Low Entry comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
