Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum, ground control geometry, 700c low entry comfort frame, formed tubes w/ integrated kickstand mount, forged dropouts w/ replaceable hanger
Suspension Fork
SR Suntour NEX-4110V2, 63mm travel, 1pc. alloy lower, Hi-Ten stanchions and steerer, coil/mcu w/ preload adjust, spring assisted seals
Drivetrain
Rear Derailleur
Shimano Acera, 8-speed
Front Derailleur
Shimano FD-C102, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano SL-MC40, 8-speed, Rapid Fire
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
Shimano FC-M191, w/ chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z8, w/ reusable Missing Link
Pedals
Comfort pedal, composite body w/rubber top, sealed loose ball bearings
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR
Rear Hub
Forged alloy, double sealed, ground race, cassette, QR, 32h
Rims
Globe 700c, double wall, 32h w/CNC side wall
Spokes
1.8mm (15g) stainless
Tires
Specialized Hemisphere Armadillo, 700x38c, 60TPI, wire bead
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
Alloy 4-finger, kraton lever pad, for Rapid Fire shifter
Cockpit
Stem
Ground control, 4-bolt, alloy head/Cr-Mo quill, 25.4mm clamp
Handlebar
Aluminum Comfort riser bar, 25.4mm, 60mm rise, 620mm wide, 15 degree back sweep, 5 degree up
Headset
1-1/8"" threaded, sealed loose ball bearings
Seat
Saddle
Comfort Plus with dual density foam and springs for extra comfort
Seatpost
Alloy suspension, 2-bolt head, 27.2mm w/ 3.8mm spring
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Front Center | 641 mm | 644 mm |
| Rake | 40 mm | 40 mm |
| Trail | 89 mm | 89 mm |
| Top Tube Length | 604 mm | 619 mm |
| Seat Tube Angle | 70 ° | 69 ° |
| Seat Tube Length | 370 mm | 425 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 504 mm | 504 mm |
| Wheelbase | 1136 mm | 1138 mm |
| Bottom Bracket Drop | 73 mm | 73 mm |
| Standover Height | 461 mm | 459 mm |
| Wheels | 700 | 700 |
About this model
Carmel 700 5 Low Entry completes the Specialized Carmel model. 16 bikes variations carry this model name so far. Take a sneak peek at all Specialized Carmel bikes models from 2010, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Comfort bikes
Our math shows that the average cost of a dependable Comfort bike is 360$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Carmel 700 5 Low Entry components
Fork
This bike has the SunTour NEX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Specialized Carmel 700 5 Low Entry 2010, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Carmel 700 5 Low Entry comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
