Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, 700c Hybrid geometry, formed tubes, integrated kickstand mount, replaceable hanger
Suspension Fork
SR Suntour NEX-4110V2, alloy lower, Hi-Ten stanchions and steerer, coil/Mcu spring, preload adjust, 63mm travel
Drivetrain
Rear Derailleur
Shimano Acera, 8-speed
Front Derailleur
Shimano, top swing, dual pull
Shift Levers
Shimano, SL-M360, Rapid Fire, 8-speed
Cassette
SRAM, 8-speed, 11-32t
Crank
Shimano FC-M171, w/chainguard
Bottom Bracket
Cartridge bearing, square spindle w/ crank stop right side, capless bolts
Chain
KMC Z8 w/ reusable Missing Link
Pedals
Comfort Pedal, composite body w/rubber top, sealed loose ball
Wheels
Front Hub
Double sealed, ground race, dual lock nuts w/ 17mm contact side, 5mm QR
Rear Hub
Double sealed, ground race, dual lock nuts w/ 19mm contact side, 5mm QR
Rims
Alloy double-wall, machined, pinned w/ eyelets, 32h
Spokes
2mm (14g) stainless
Tires
Specialized Hemisphere Armadillo, 60 TPI, 700x38c
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
Alloy 4-finger, Kraton lever for Rapidfire shifter
Cockpit
Stem
Ground Control adjustable rise, alloy head/quill, 2-bolt, 25.4mm clamp
Handlebar
Comfort riser bar, alloy, 60mm rise, 15-degree sweep, 25.4mm
Headset
1-1/8"" threaded, sealed loose ball bearings
Seat
Saddle
Comfort Plus, dual-density foam, springs
Seatpost
A-1 Suspension Seatpost, alloy, 27.2mm w/ 3.8mm spring
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 641 mm | 657 mm | 679 mm | 695 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 89 mm | 89 mm | 93 mm | 93 mm |
| Top Tube Length | 594 mm | 609 mm | 624 mm | 639 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 370 mm | 425 mm | 480 mm | 535 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69 ° | 69 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1106 mm | 1122 mm | 1144 mm | 1160 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 728 mm | 763 mm | 805 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Crossroads Elite completes the Specialized Crossroads model. Specialized launched 47 bikes of this model so far. Check out the entire range from 2012 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crossroads Elite components
Fork
Specialized Crossroads Elite 2012 bike is equipped with the SunTour NEX fork, and has 63mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Crossroads Elite has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Specialized Crossroads Elite 2012, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized Crossroads Elite has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Crossroads Elite comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
