Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork RST
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, formed TT, ORE DT, forged dropouts w/ replaceable 98954020 hanger, integrated kickstand mount, chainstay disc mount
Suspension Fork
RST Neon Pro ML700, 75mm, Hi-Ten steerer, 28.6mm stanchions, 1pc. alloy lower w/ disc mount, coil/mcu w/ preload adj. spring type seal
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano FD-M530, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano Deore SL- M531, 9-speed, rapid fire
Cassette
Shimano HG-50, 9-speed, 11-32t
Crank
Sugino XD500TG w/ chainguard
Bottom Bracket
FSA BB-7420, cartridge bearings, 68mm x 122.5mm for 47.5mm chain line
Chain
KMC X9 w/ reuseable Missing Link
Pedals
Composite body, 9/16""
Wheels
Front Hub
Specialized, forged alloy, double sealed, polished races, 32h, steel QR
Rear Hub
Specialized, forged alloy, double sealed, ground race, cassette, QR, 32h
Rims
Specialized/Alex Crosstrail, 700c, double wall w/ machine sidewalls, 32h
Spokes
1.8mm (15g) stainless
Tires
Specialized Borough XC Sport 700x45c, 60TPI, wire bead
Brakes
Brakes
Alloy linear pull w/ adj. housing, 1pc. pad
Brake Levers
Specialized linear pull
Cockpit
Stem
Specialized forged alloy, 2-bolt, 25.4mm, 15 degree rise
Handlebar
Specialized alloy riser bar, 25.4mm, 25mm rise, 620mm wide, 8 degree back sweep, 8 degree up
Grips
Specialized Enduro, closed end, 130mm
Headset
Specialized 1-1/8"" threadless, loose ball
Seat
Saddle
Specialized XC, Body Geometry, 143mm width, front and rear bumpers
Seatpost
Specialized alloy two bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXL | XL | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 0.92 mm | 0.86 mm | 0.66 mm | 0.73 mm | 0.8 mm |
| Stack | 575 mm | 524 mm | 372 mm | 423 mm | 474 mm |
| Reach | 626 mm | 611 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Head Tube Length | 175 mm | 175 mm | 170 mm | 170 mm | 170 mm |
| Wheelbase | 611 mm | 611 mm | 611 mm | 611 mm | 611 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 68 mm | 69 mm | 69 mm |
| Standover Height | 96 mm | 96 mm | mm | mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Crosstrail Elite is a Specialized Crosstrail model. Specialized released 50 bikes variations of this model so far. You can get a glimpse at all models from 2009, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosstrail Elite components
Fork
The Crosstrail Elite comes factory-installed with the RST fork. This has a travel range of 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The Crosstrail Elite 2009 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Crosstrail Elite is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
