Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, microSHIFT MTB -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 SL Premium Aluminum, Fitness Geometry, fully-manipulated butted tubing, internal cable routing, flat mount disc, rack & Plug + Play mounts
Drivetrain
Rear Derailleur
Shimano Alivio, Shadow design, SGS cage, 9-speed
Front Derailleur
microSHIFT, 31.8mm clamp, 9-speed, MTB double
Shift Levers
microSHIFT MTB, 9-speed
Cassette
Sunrace, 9-speed, 11-36t
Crank
FSA Alpha Drive, forged 6061 aluminum, 44/32T w/chainguard
Bottom Bracket
FSA BB-7420ST
Pedals
Specialized Fitness platform
Wheels
Front Hub
Specialized Center Lock, loose ball bearings, 32h, 9mm QR
Rear Hub
Shimano Center Lock disc, 8-/9-/10-speed freehub, 135mm axle, 32h
Rims
700c disc, 6061 aluminum double-wall
Spokes
Stainless, 14g
Tires
Trigger Sport Reflect, 700x38mm, 60TPI, wire bead
Brakes
Brakes
Tektro Vela, hydraulic disc, post mount, organic pads, 160mm rotor
Cockpit
Stem
3D forged aluminum, 7-degree rise, 31.8mm clamp
Handlebar
Specialized, double-butted alloy, 9-degree backsweep, 31.8mm
Grips
Body Geometry Flow Set Control Grips, lock-on
Seat
Saddle
Canopy Sport, steel rails
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.528 mm | 1.529 mm | 1.521 mm |
| Front Center | 630 mm | 641 mm | 655 mm | 680 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 87 mm | 84 mm | 84 mm | 84 mm |
| Stack | 594 mm | 611 mm | 630 mm | 648 mm |
| Reach | 390 mm | 400 mm | 412 mm | 426 mm |
| Top Tube Length | 572 mm | 587 mm | 604 mm | 624 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1067 mm | 1078 mm | 1096 mm | 1117 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 740 mm | 776 mm | 813 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Crosstrail Sport belongs to the Specialized Crosstrail model. 50 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Crosstrail Sport components
Wheels size
As for the wheels, Specialized Crosstrail Sport 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
