Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 55mm -
Fork SunTour NEX
-
Groupset Alivio, microSHIFT Marvolt -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 SL Premium Aluminum, Fitness Geometry, fully-manipulated butted tubing, internal cable routing, flat-mount disc, quick-release, Plug + Play rack & fender mounts
Suspension Fork
SR Suntour NEX w/ Specialized Fitness Brain technology, 1-1/8" steerer, QR, fender mounts, 55mm of travel
Drivetrain
Rear Derailleur
Shimano Alivio, Shadow Design, SGS cage, 9-speed
Front Derailleur
microSHIFT Marvo LT, 31.8mm clamp
Shift Levers
microSHIFT, 9-speed
Cassette
SunRace, 9-Speed, 11-36t
Crank
FSA Alpha Drive, 3-piece, 44/32T
Bottom Bracket
BSA, square-taper, 68mm
Chain
KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
Pedals
Specialized Body Geometry Fitness, platform, plastic
Wheels
Front Hub
Shimano Center Lock™ disc, loose ball bearings, quick-release, 32h
Rear Hub
Shimano Center Lock™ disc, loose ball bearings, quick-release, 10-speed freehub, 32h
Rims
700C disc, 6061 aluminum, double-wall
Spokes
Stainless, 14g
Tires
Trigger Sport Reflect, 60 TPI, wire bead, 700x38mm
Brakes
Brakes
Tektro HD-R305, hydraulic disc, resin pads, post-mount, 160mm Center Lock™
Cockpit
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Handlebar
Double-butted alloy, 9-degree backsweep, 31.8mm
Seat
Saddle
Specialized Canopy Sport, steel rails, 155mm
Seatpost
Alloy, 12mm offset, 2-bolt clamp, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.528 mm | 1.529 mm | 1.521 mm |
| Front Center | 630 mm | 641 mm | 655 mm | 680 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 87 mm | 84 mm | 84 mm | 84 mm |
| Stack | 594 mm | 611 mm | 630 mm | 648 mm |
| Reach | 390 mm | 400 mm | 412 mm | 426 mm |
| Top Tube Length | 572 mm | 587 mm | 604 mm | 624 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | ° | 70 ° |
| Head Tube Length | 110 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1067 mm | 1078 mm | 1096 mm | 1117 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 740 mm | 776 mm | 813 mm | mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
CrossTrail Sport belongs to the Specialized Crosstrail model. Specialized released 50 bikes variations of this model so far. Take a sneak peek at all Specialized Crosstrail bikes models from 2019, by clicking here.
Model range prices
Specialized CrossTrail – Mechanical Disc 2019 is the cheapest bike model and costs 525$. Specialized CrossTrail Elite 2019 is the most expensive one and costs 1200$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Specialized released this model in 2019, its price was 850$. Comparing this to the average Fitness bike price, we see that the price is 29.57% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This bike has the SunTour NEX fork installed. The fork’s travel is 55mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the CrossTrail Sport model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized CrossTrail Sport is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Specialized CrossTrail Sport bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
