Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized E5 aluminum, fully manipulated tubing, smooth weld, semi-compact race design, shaped TT, integrated headset, 1-1/2"" lower bearing, internal cable routing, OSBB
Suspension Fork
Specialized FACT carbon, 1-1/2"" lower bearing, disc only
Drivetrain
Rear Derailleur
New Shimano Tiagra 10-speed
Front Derailleur
New Shimano Tiagra 10-speed
Shift Levers
New Shimano Tiagra STI 10-speed
Cassette
New Shimano Tiagra, 10-speed, 12-28t
Crank
FSA Omega compact BB30 ST
Bottom Bracket
With crankset
Chain
New Shimano Tiagra 10-speed
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Front Hub
Forged alloy Disc hub, 32h
Rear Hub
Forged aluminum Disc hub, double sealed ball bearings, cassette, QR, 32h
Rims
Alex S480, 32h
Spokes
Stainless 14g
Tires
Specialized Tracer Sport, 60 TPI, wire bead, 700x33c
Brakes
Brakes
Avid BB5 disc, 160mm
Brake Levers
SRAM Rival
Cockpit
Stem
Specialized EliteSet, 3D forged alloy, 12-degree, 4-position adjustable, 4-bolt, 31.8mm clamp
Handlebar
Specialized CX Comp, alloy, short drop
Headset
1-1/8"" upper and 1-1/2"" lower Cr-Mo cartridge bearings integrated, w/ headset, 20mm cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Phenom Comp, hollow Cr-Mo rails
Seatpost
Specialized Sport, alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.47 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.59 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 275 mm | 275 mm | 277 mm | 277 mm |
| Front Center | 593 mm | 595 mm | 595 mm | 601 mm | 606 mm | 609 mm | 615 mm |
| Rake | 51 mm | 51 mm | 51 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 75 mm | 69 mm | 62 mm | 64 mm | 61 mm | 58 mm | 55 mm |
| Stack | 514 mm | 533 mm | 546 mm | 559 mm | 575 mm | 589 mm | 610 mm |
| Reach | 358 mm | 362 mm | 367 mm | 371 mm | 376 mm | 379 mm | 384 mm |
| Top Tube Length | 502 mm | 508 mm | 529 mm | 541 mm | 549 mm | 562 mm | 579 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1000 mm | 1001 mm | 1001 mm | 1008 mm | 1014 mm | 1017 mm | 1023 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 756 mm | 774 mm | 787 mm | 801 mm | 817 mm | 833 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
CruX Comp Disc is part of the Specialized Crux model. Specialized released 94 bikes variations of this model so far. You can easily view all of the Specialized Crux bikes models from 2012, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
CruX Comp Disc components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the CruX Comp Disc model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CruX Comp Disc has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
