Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Travel Rear 90mm -
Fork RockShox Reba
-
Groupset X9, SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Epic FSR M5 alloy, 29"" geometry, fully manipulated frame w/ ORE DT/TT, sealed cartridge bearings, 90mm travel, replaceable derailleur hanger
Suspension Fork
Rock Shox Reba SL 29, custom tuned for Specialized, 100mm of travel, air spring, alloy tapered steer, compression and rebound adj. w/ LO
Rear Shock
Fox/SBC remote Mini-Brain, inertia valve, w/ Brain fade adjust
Drivetrain
Rear Derailleur
SRAM X-9, 9-speed long cage
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Shift Levers
SRAM X-7, aluminum trigger
Cassette
Shimano HG61, 9-speed, 11-34t
Crank
Custom Shimano FC-M542, 175mm
Bottom Bracket
Custom Shimano, outboard bearing
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
None
Wheels
Front Hub
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, oversized end caps, 9mm DT RWS, alloy QR, 28h
Rear Hub
Custom Shimano M525 SL, alloy QR, 32h
Rims
Custom DT Swiss X450SL, 29"" rim, 24mm w/ eyelets, 32h
Spokes
DT Swiss 1.8mm stainless
Tires
S-Works The Captain, 29x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
Brakes
Brakes
Custom Avid Elixir R SL, alloy backed organic pads, M: 160mm, L/XL: 185mm rotor
Brake Levers
Custom Avid Elixir R SL Hydraulic, tool-less adj. reach
Cockpit
Stem
3D forged alloy, adjustable rise, 31.8mm clamp
Handlebar
Specialized XC flat, 2014 butted alloy, 660mm wide, 8 degree backsweep, 31.8mm
Grips
Specialized waffle lock on grip (S/M) Specialized Thick lock on grip (L/XL)
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower cartridge bearing
Seat
Saddle
Specialized Phenom, hollow Cr-Mo rails, thin foam, S/M: 130mm, L/XL: 143mm
Seatpost
2014 butted alloy, single bolt setback, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Stack | 603 mm | 612 mm | 631 mm |
| Reach | 409 mm | 432 mm | 456 mm |
| Top Tube Length | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1103 mm | 1130 mm | 1157 mm |
| Bottom Bracket Drop | 16 mm | 16 mm | 16 mm |
| Standover Height | 761 mm | 773 mm | 775 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Epic Comp 29 completes the Specialized Epic model. 161 bikes variations carry this model name so far. You can easily view all of the Specialized Epic bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Epic Comp 29 components
Fork
This bike has the RockShox Reba fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
Epic Comp 29 has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Specialized Epic Comp 29 bike has the Fox/SBC remote Mini-Brain model installed, and has a travel of 90mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Epic Comp 29 model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Epic Comp 29 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
