Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Reba
-
Groupset X9, SRAM -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 alloy, 29"" geometry, tapered headtube, full internal shift/brake routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm
Suspension Fork
RockShox Reba RL 29, Solo Air spring, tapered alloy steerer, w/ lockout, compression, rebound adjust, 15mm thru-axle, 100mm travel
Rear Shock
FOX/Specialized remote Mini-Brain w/ AUTOSAG, inertia valve, BrainFade adjust, 205x53mm, 100mm travel
Drivetrain
Rear Derailleur
SRAM X9 Type 2, 10-speed, mid cage
Front Derailleur
Custom SRAM, 2X10, high direct mount
Shift Levers
SRAM X7, 10-speed, w/ MatchMaker clamp
Cassette
SRAM PG 1030, 10-speed, 11-36
Crank
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC double, PF30 spindle, 36/22, 104/64mm BCD spider
Bottom Bracket
SRAM, PF30, OS press-in bearings, sealed cartridge
Chain
SRAM PC 1031, 10-speed, w/ PowerLink, nickel finish
Pedals
Resin test ride, w/ toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h
Rear Hub
Specialized Hi Lo disc, 4 sealed cartridge bearings, 12mm thru-axle, 32h
Rims
Roval 29, alloy, 21mm inner width, 32h
Spokes
DT Swiss Industry, stainless
Tires
S-Works Fast Trak Control, 120TPI, 2Bliss Ready, folding bead, 29x2.2""
Brakes
Brakes
Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, Storm SL rotor, S/M: 160mm rotor, Others: 180mm
Brake Levers
Magura MTS, alloy lever
Cockpit
Stem
Specialized, forged alloy, 6-degree rise
Handlebar
Specialized flat, 8-degree backsweep, 31.8mm
Grips
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL
Headset
1-1/8"" and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost
Specialized alloy, single bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.438 mm | 1.395 mm | 1.372 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 647 mm | 667 mm | 695 mm | 723 mm |
| Rake | 56 mm | 46 mm | 46 mm | 47 mm |
| Trail | 73 mm | 84 mm | 84 mm | 83 mm |
| Stack | 587 mm | 601 mm | 615 mm | 634 mm |
| Reach | 393 mm | 418 mm | 441 mm | 462 mm |
| Top Tube Length | 568 mm | 593 mm | 620 mm | 647 mm |
| Seat Tube Angle | 73.75 ° | 73.75 ° | 73.75 ° | 73.75 ° |
| Seat Tube Length | 400 mm | 434 mm | 470 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1092 mm | 1112 mm | 1140 mm | 1168 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 776 mm | 781 mm | 791 mm | 793 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Epic Comp 29 belongs to the Specialized Epic model. 161 bikes variations carry this model name so far. Take a sneak peek at all Specialized Epic bikes models from 2015, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The RockShox Reba is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Epic Comp 29 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
As for the rear shock, this bike has the FOX/Specialized remote Mini-Brain w/ AUTOSAG model, with a travel of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Epic Comp 29 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Epic Comp 29 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
