Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 95mm -
Fork RockShox Reba
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 alloy, XC 29 Geometry, tapered head tube, internal cable routing, 12x142mm dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger
Suspension Fork
Custom RockShox Reba RL, rebound adjust, Solo Air spring, tapered alloy crown/steerer, 15x100mm Maxle Stealth thru-axle, 80/95mm of travel, 51mm offset
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, Shadow Plus, SGS cage, 11-speed
Front Derailleur
Shimano SLX 7025, direct-mount, down-swing
Shift Levers
Shimano SLX M7000, 11-speed
Cassette
SRAM PG-1130, 11-speed, 11-42t
Crank
RaceFace Aeffect, 6000-series alloy, 24mm spindle, 49mm chainline, 34/24T
Chain
SRAM PC-1110, 11-speed w/PowerLink
Wheels
Front Hub
Specialized disc, alloy, sealed cartridge bearings,15x100mm thru-axle, 32h
Rear Hub
Specialized disc, alloy, 6-bolt disc, sealed cartridge bearings, 12x142mm thru-axle, 28h
Rims
Specialized Stout, alloy hookless bead, 32h
Spokes
Stainless, black, 14g
Tires
Fast Trak, Control casing, 29x2.2"", 60TPI, Aramid folding bead, 2Bliss Ready
Brakes
Brakes
Shimano M506, hydraulic disc, resin pad, 180/160mm rotor
Cockpit
Stem
Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Handlebar
Stout XC, double-butted alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 720mm width, 31.8mm
Grips
Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
Seat
Saddle
Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost
Specialized Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.48 mm | 1.44 mm | 1.4 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 624 mm | 655 mm | 682 mm | 708 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 586 mm | 604 mm | 619 mm | 633 mm |
| Reach | 384 mm | 408 mm | 431 mm | 452 mm |
| Top Tube Length | 559 mm | 587 mm | 614 mm | 637 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 394 mm | 434 mm | 470 mm | 505 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1041 mm | 1072 mm | 1099 mm | 1125 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 754 mm | 793 mm | 820 mm | 843 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Epic Hardtail completes the Specialized Epic Hardtail model. 48 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Epic Hardtail components
Fork
The RockShox Reba is included from the factory. It has a travel distance of 95mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Epic Hardtail model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
