Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 100mm -
Travel Rear 100mm -
Groupset X0, XT -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 9m carbon front triangle, IS construction, M5 aluminum rear triangle. sealed cartridge bearing pivots, 100mm travel, replaceable derailleur hanger
Suspension Fork
Specialized Future Shock e100, inertia valve, 100mm travel, Brain Fade, external rebound adj. single sided air spring and damper, carbon 1-1/8"" to 1.5"" steerer
Rear Shock
Fox/SBC remote Mini-Brain, inertia valve, w/ Brain fade adjust
Drivetrain
Rear Derailleur
SRAM X-0, 9-speed, mid cage
Front Derailleur
Shimano M770 XT, DMD, top swing, dual pull
Shift Levers
SRAM X-0, carbon/aluminum trigger
Cassette
Shimano M770 XT, 9-speed, 11-34t
Crank
Shimano FC-M770 XT, 2pc. S: 170mm, others: 175mm
Bottom Bracket
Custom Shimano BB-91, OS, press-in bearing
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
None
Wheels
Front Hub
Roval Control AL, alloy, oversize 28mm end caps
Rear Hub
Roval Control AL with alloy freehub
Rims
Roval Control AL, disc, 24mm
Tires
S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
Brakes
Brakes
Custom Avid Elixir R CR MAG, alloy caliper, alloy backed semi-metallic pads, SS harware package,S/M: 160mm, L/XL: 185mm rotor
Brake Levers
Custom Avid Elixir R CR MAG, magnesium body, carbon lever, tool-less reach adjust
Cockpit
Stem
3D forged alloy, adjustable rise, 31.8mm clamp
Handlebar
S-Works XC Carbon low-rise bar, uni-directional carbon, 31.8mm, 660mm wide, 8 degree back sweep, 6 degree up
Grips
Specialized waffle lock on grip (S/M) Specialized Thick lock on grip (L/XL)
Headset
1 1/8"" - 1 1/2"" Threadless, Campy style upper and lower cartridge bearing.
Seat
Saddle
Specialized Phenom SL, Ti rails, thin foam, S/M: 130mm, L/XL: 143mm
Seatpost
Thomson Elite Setback w/ 12 degree clamp, S/M: 367mm L/XL:410mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.33 mm | 1.3 mm | 1.29 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Stack | 541 mm | 561 mm | 579 mm | 598 mm |
| Reach | 394 mm | 423 mm | 444 mm | 464 mm |
| Top Tube Length | 548 mm | 583 mm | 609 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 444 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 126 mm | 144 mm | 154 mm | 184 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1055 mm | 1092 mm | 1120 mm | 1147 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 720 mm | 741 mm | 751 mm | 769 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Epic Marathon Carbon is part of the Specialized Epic model. Specialized released 161 bikes variations of this model so far. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Epic Marathon Carbon components
Fork material
Epic Marathon Carbon has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Rear Shock
As for the rear shock, this bike has the Fox/SBC remote Mini-Brain model, with a travel of 100mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Epic Marathon Carbon are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Epic Marathon Carbon comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Epic Marathon Carbon comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
