Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 90mm -
Travel Rear 90mm -
Fork RockShox Reba
-
Groupset XT, X7 -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 9m carbon front triangle, M5 alloy rear triangle, FACT IS construction, tapered headtube, carbon PF30 BB, full internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, SWAT EMT tool cradle, S: 90mm travel, M/L: 100mm
Suspension Fork
RockShox Reba RL 29, Solo Air spring, tapered alloy steerer, w/ lockout, compression, rebound adjust, 15mm thru-axle, S: 90mm travel, M/L: 100mm
Rear Shock
FOX/Specialized remote Mini-Brain w/ AUTOSAG, inertia valve, BrainFade adjust, 200x48mm, 95mm travel
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus, 10-speed, SGS long cage
Front Derailleur
SRAM X7, 2x10, high direct mount
Shift Levers
Shimano SLX, 10-speed, trigger
Cassette
SRAM PG 1030, 10-speed, 11-36
Crank
Custom SRAM S-1250, 7050 alloy arms, 10-speed AM double, PF30 spindle, 104/64mm BCD spider
Bottom Bracket
SRAM, PF30, OS press-in bearings, sealed cartridge
Chain
SRAM PC 1031, 10-speed, w/ PowerLink, nickel finish
Pedals
Resin test ride, w/ toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h
Rear Hub
Specialized Hi Lo disc, 4 sealed cartridge bearings, 12mm thru-axle, 32h
Rims
Roval 29, alloy, 21mm inner width, 32h
Spokes
DT Swiss Industry, stainless
Tires
S-Works Fast Trak Control, 120TPI, 2Bliss Ready, folding bead, 29x2.2""
Brakes
Brakes
Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, Storm SL rotor
Brake Levers
Magura MTS, alloy lever
Cockpit
Stem
Specialized, forged alloy, 6-degree rise
Handlebar
Specialized flat, 8-degree backsweep, 31.8mm
Grips
Specialized Sip Grip, lock-on, half-waffle, S/M: regular thickness, L: XL thickness
Headset
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Women's Myth Comp, hollow Cr-Mo rails, 155mm
Seatpost
Specialized alloy, single bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.39 mm |
| Bottom Bracket Height | 322 mm | 327 mm | 332 mm |
| Front Center | 631 mm | 664 mm | 692 mm |
| Rake | 45 mm | 48 mm | 51 mm |
| Trail | 85 mm | 82 mm | 79 mm |
| Stack | 588 mm | 597 mm | 606 mm |
| Reach | 387 mm | 414 mm | 437 mm |
| Top Tube Length | 545 mm | 574 mm | 600 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 382 mm | 420 mm | 445 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 95 mm | 105 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1075 mm | 1107 mm | 1134 mm |
| Bottom Bracket Drop | 40 mm | 45 mm | 50 mm |
| Standover Height | 725 mm | 734 mm | 743 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Era Comp Carbon 29 completes the Specialized Era model. Specialized launched 20 bikes of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Era Comp Carbon 29 components
Fork
The fork installed on this bike is the RockShox Reba model. The travel on this model is 90mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
From the factory, it comes with the FOX/Specialized remote Mini-Brain w/ AUTOSAG rear shock model, which has a travel of 90mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the Era Comp Carbon 29 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Era Comp Carbon 29 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
