Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1 Premium Aluminum, Ground Control Geometry, 26"" frame, formed tubes, forged dropouts w/ replaceable derailleur hanger
Suspension Fork
SR Suntour NEX Coil, aluminum lower, preload adj. 63mm travel
Drivetrain
Rear Derailleur
Shimano, 7-speed
Shift Levers
Shimano, 7-speed, Revo-shift
Cassette
Shimano MegaRange, 7-speed, 14-34
Crank
Forged crank arm w/ press on ring, double PC ring guard
Bottom Bracket
Cartridge bearings, square spindle, capless bolts
Chain
KMC Z7
Pedals
Comfort, composite body w/ rubber top, sealed loose ball bearings
Wheels
Front Hub
Double-sealed, ground race, dual-lock nuts w/ 17mm contact side, 5mm QR
Rear Hub
Freewheel type, nutted
Rims
Alloy double-wall, 32h
Spokes
Stainless, 14g (2.0mm)
Tires
Specialized Hemisphere, 26x1.95"", wire bead, Flak Jacket protection, 26 TPI
Brakes
Brakes
Die-cast, alloy V-brake, 60mm 1pc. pad, linear pull
Brake Levers
Alloy, four-finger lever
Cockpit
Stem
Quill, alloy die-cast, 2-bolt, 150mm x 25.4mm clamp
Handlebar
Specialized riser bar, alloy, 15-degree backsweep, 60mm rise, 25.4mm
Headset
1-1/8"" FSA Intelaset, threaded, Cr-Mo cups
Seat
Saddle
Comfort Plus, dual-density foam, springs
Seatpost
Alloy, 2-bolt, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 630 mm | 644 mm | 665 mm | 679 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm |
| Top Tube Length | 614 mm | 629 mm | 644 mm | 659 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67.5 ° | 67.5 ° |
| Seat Tube Length | 370 mm | 425 mm | 480 mm | 535 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 504 mm | 504 mm | 504 mm | 504 mm |
| Wheelbase | 1127 mm | 1142 mm | 1163 mm | 1177 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 59 mm | 59 mm |
| Standover Height | 695 mm | 740 mm | 785 mm | 828 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Expedition belongs to the Specialized Expedition model. Specialized launched 16 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Comfort bikes average price
If you want an acceptable Comfort bike you should know that the average price is 360$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Expedition components
Fork
The SunTour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the Expedition model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Expedition comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
