Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset SLX, Deore -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FSR XC M4 tubing, rocker design, bolt on cable guides, 120mm travel, sealed cartridge pivot bearings, disc only, replaceable rear derailleur hanger
Suspension Fork
Rock Shox Tora SLite, 120mm travel, alloy steer, magnesium lower, rebound and preload adj. w/ LO
Rear Shock
X Fusion 02RLA, Custom tuned for Specialized, rebound adj. w/ LO, 7.5x1.75"", 2 bearing upper shock mount
Drivetrain
Rear Derailleur
Shimano RD-M662 SLX Shadow, long cage
Front Derailleur
Shimano FD-M590 Deore, 34.9mm clamp, top swing, bottom pull
Shift Levers
Shimano SL-M531 Deore, trigger
Cassette
Shimano HG50, 9-speed, 11-34t
Crank
Shimano FC-M442, Octalink Spline, replaceable rings w/ alloy outer, S: 170mm, others: 175mm
Bottom Bracket
Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm x 118mm
Chain
KMC X9 w/ reuseable Missing Link
Pedals
Alloy body and cage, 9/16""
Wheels
Front Hub
Forged alloy, hi/low flange, double sealed, ground race, machined disc mount, 32h
Rear Hub
Disc, double sealed system, high/low flange w/ OS contact side, 32h, QR
Rims
Rim brake specific, double wall w/ eyelets, CNC sidewall
Spokes
1.8mm (15g) stainless
Tires
Specialized The Captain Sport, 26.2.2"", 60 TPI, wire bead
Brakes
Brakes
Avid SD3, alloy linear pull w/ 1pc pad
Brake Levers
Avid FR-5, alloy, two-finger, linear pull
Cockpit
Stem
3D forged alloy, 4-bolt, 31.8mm, adjustable rise
Handlebar
XC low rise, 6061 butted alloy, 660mm wide, 8 degree back sweep, 6 degree up
Grips
Specialized waffle lock on grip (S/M) Specialized thick lock on grip (L/XL)
Headset
1-1/8"" threadless, loose ball
Seat
Saddle
Specialized Rival, Body Geometry, 143mm width, front and rear bumpers
Seatpost
6061 alloy, 2-bolt micro adjust setback head, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.3 mm | 1.3 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 554 mm | 573 mm | 591 mm | 610 mm |
| Reach | 395 mm | 424 mm | 453 mm | 468 mm |
| Top Tube Length | 550 mm | 584 mm | 619 mm | 639 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 534 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1080 mm | 1116 mm | 1153 mm | 1175 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 711 mm | 718 mm | 726 mm | 732 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
FSRxc completes the Specialized Fsrxc model. Specialized released 10 bikes variations of this model so far. Check out the entire range from 2010 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
Specialized FSRxc bike has the X Fusion 02RLA model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Specialized FSRxc 2010, has a 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The FSRxc has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
FSRxc comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
